PRODUCT INFORMATION
Product Overview
The ABB ACS580-01-011A-6 3AXD50000271085 is an ACS580 series AC drive. It operates on a three-phase input voltage range from 525 to 600 V AC. The drive supports standard input supply frequencies of 50 Hz and 60 Hz. Under light-overload conditions, this hardware provides an output power of 10 HP (7.5 kW). For heavy-duty industrial cycles, the unit provides 7.5 HP (5.5 kW) output power.
This AC drive is manufactured in an R2 frame size for wall-mount placement. The mechanical housing provides an IP21 protection rating alongside a NEMA Type 1 enclosure rating. It delivers a continuous rated output current of 11 A for light-overload duty. For heavy-duty operation, the equipment delivers a rated output current of 9 A. This unit provides continuous motor regulation across specified electrical and thermal duty limits.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input Voltage | 525 - 600 V AC, 3-phase |
|---|
| Frequency | 50/60 Hz |
|---|
| Output Current | 9 A heavy-duty / 11 A light-overload |
|---|
| Output Power | 7.5 HP (5.5 kW) heavy-duty / 10 HP (7.5 kW) light-overload |
|---|
| Frame Size | R2 |
|---|
| Mounting Type | Wall-mount |
|---|
| Protection Rating | IP21 |
|---|
| Enclosure Rating | NEMA Type 1 |
|---|
TECHNICAL INFORMATION
Features
- Provides 10 HP (7.5 kW) output power during light-overload operating profiles.
- Supplies 7.5 HP (5.5 kW) output power during heavy-duty industrial operation.
- Accepts a three-phase line supply voltage from 525 V to 600 V AC.
- Operates with alternating current line frequencies of 50 Hz or 60 Hz.
- Constructed in an R2 frame size designed for direct wall-mount installation.
- Features an IP21 degree of protection with a NEMA Type 1 rating.
TECHNICAL INFORMATION
Applications
- Three-phase motor regulation within 525 V to 600 V industrial electrical distribution networks.
- Industrial motor circuits requiring continuous operation up to 11 A light-overload current.
- Machinery drives requiring up to 9 A continuous current for heavy-duty operating profiles.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the R2 frame enclosure directly to a wall using suitable hardware.
- Ensure incoming electrical supply matches the 525 V to 600 V AC three-phase specification.
- Verify that the operating environment aligns with the IP21 and NEMA Type 1 enclosure ratings.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What are the power and current ratings for the ABB ACS580-01-011A-6?
It provides 10 HP (11 A) for light-overload and 7.5 HP (9 A) for heavy-duty service.
What electrical input supply is required by this ACS580 drive?
The drive requires a three-phase input supply of 525 to 600 V AC at 50/60 Hz.
What is the reference price for the ABB 3AXD50000271085 drive?
Observed market reference pricing is $2,596 USD. These figures are indicative market reference pricing only and are not a final quotation.
