PRODUCT INFORMATION
Product Overview
The ABB ACS800-01-0050-5 64576534 is an AC drive designed for the ACS800 product series. This wall-mounted unit operates on a three-phase input supply between 380 and 500 VAC. It supports an input frequency range spanning from 48 to 63 Hz. Built in an R5 frame size, it features an IP21 protective enclosure.
The variable frequency drive delivers a continuous output power rating of 37 kW. It maintains a continuous output current rating of 65 A during normal operation. For heavy-duty industrial tasks, the unit provides 30 kW with a 50 A output current. Light-overload operating conditions support an output current capacity up to 61 A. The complete drive assembly weighs 34 kg with compact standard cabinet or wall installation.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input phases | 3 |
|---|
| Nominal input voltage | 380–500 VAC |
|---|
| Nominal input frequency | 48–63 Hz |
|---|
| Continuous output current | 65 A |
|---|
| Continuous output power | 37 kW |
|---|
| Light-overload output current | 61 A |
|---|
| Heavy-duty output current | 50 A |
|---|
| Heavy-duty output power | 30 kW |
|---|
| Frame size | R5 |
|---|
| Enclosure | IP21 |
|---|
| Mounting | Wall mounting |
|---|
| Product height | 739 mm |
|---|
| Product width | 265 mm |
|---|
| Product depth | 286 mm |
|---|
| Product weight | 34 kg |
|---|
TECHNICAL INFORMATION
Features
- Operates with three-phase input voltage from 380 to 500 VAC.
- Provides 37 kW continuous output power and 65 A continuous current.
- Delivers 30 kW power with 50 A current under heavy-duty demands.
- Engineered in an R5 physical frame size for wall mounting.
- Features an integrated IP21 industrial protective enclosure rating.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the drive vertically to a flat, solid wall surface using designated R5 frame points.
- Provide sufficient clearance around the IP21 enclosure for unimpeded cooling airflow.
- Verify incoming three-phase supply lines meet the 380 to 500 VAC electrical rating.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure motor parameters to match heavy-duty 30 kW or continuous 37 kW operational limits.
- Set application protection thresholds corresponding to continuous 65 A or heavy-duty 50 A current.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the rated power of the ABB ACS800-01-0050-5 drive?
The unit provides 37 kW continuous output power and 30 kW under heavy-duty operating loads.
What input power does the 64576534 AC drive require?
It requires a three-phase input supply of 380 to 500 VAC at 48 to 63 Hz.
What frame size and enclosure does this drive feature?
The drive uses an R5 frame size with a standard IP21 rated enclosure for wall mounting.
