PRODUCT INFORMATION
Product Overview
The ABB IMMPI02 is a Bailey INFI 90 Multi-Function Processor Interface auxiliary I/O module. It operates with the IMMFP03 Multi-Function Processor and INICT03 transfer module. The circuit board incorporates an integrated 40 megabyte hard disk drive for data storage. It interfaces host systems through NIMP01 or NIMP02 termination units.
Hardware jumpers J1 and J2 configure the serial communication handshaking signals. The module manages CTS and RTS hardware flow control for RS-485 interfaces. Dual universal asynchronous receiver-transmitter circuits route discrete input and output connections across edge connectors P1 through P7.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Storage Capacity | 40 Megabyte Hard Disk Drive |
|---|
| Module Function | Auxiliary I/O Card / Processor Interface |
|---|
| Supported Main Processors | IMMFP03, INICT03 |
|---|
| Supported Termination Units | NIMP01, NIMP02 |
|---|
| Hardware Handshake Lines | CTSB, RTSB |
|---|
| Handshake Jumper Headers | J1, J2 |
|---|
| Internal Bus Interfaces | P1, P2, P3, P4, P5, P6, P7 |
|---|
| Signal Routing Circuitry | Dual Universal Asynchronous Receiver-Transmitter (DUART) |
|---|
TECHNICAL INFORMATION
Features
- Includes an on-board 40 megabyte hard disk drive for auxiliary storage.
- Configures CTSB and RTSB hardware handshaking through jumper blocks J1 and J2.
- Integrates with IMMFP03 processors and INICT03 network computer transfer modules.
- Routes auxiliary signals through connectors P1 through P7.
TECHNICAL INFORMATION
Applications
- Auxiliary data storage for Bailey INFI 90 IMMFP03 control processors.
- Host communication interface routing for INICT03 transfer modules.
- RS-485 hardware handshake signal adaptation for plant computer links.
TECHNICAL INFORMATION
Connections / Interfaces
- Edge connectors P1, P2, and P3 interface with system backplanes and modules.
- Connectors P4, P5, P6, and P7 provide internal board interconnects and drive routing.
- Pin P3-10 and P3-25 route CTSB and digital input lines.
- Pin P3-14 and P3-29 route RTSB and digital output lines.
TECHNICAL INFORMATION
Installation Guidelines
- Set jumpers J1 and J2 prior to inserting the board into service.
- Handle the circuit board following standard antistatic protection measures.
- Secure interface cable connections to the associated NIMP termination module.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure jumper J1 to assign CTSB handshaking or digital input 1.
- Configure jumper J2 to assign RTSB handshaking or digital output 2.
- Verify host processor firmware settings recognize the auxiliary interface module.
TECHNICAL INFORMATION
Compatibility
- Compatible with Bailey INFI 90 IMMFP03 Multi-Function Processor modules.
- Operates alongside the INICT03 INFI-NET to Computer Transfer Module.
- Connects to NIMP01 and NIMP02 multi-function processor termination modules.
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- The IMMPI02 provides hard disk storage not present on the IMMPI01 interface card.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with Bailey INFI 90 IMMFP03 Multi-Function Processor modules. Operates alongside the INICT03 INFI-NET to Computer Transfer Module. Connects to NIMP01 and NIMP02 multi-function processor termination modules.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the ABB IMMPI02?
The IMMPI02 functions as an auxiliary processor interface card featuring an integrated 40 megabyte hard disk drive.
How does the IMMPI02 differ from the IMMPI01?
The IMMPI02 includes an on-board 40 megabyte hard disk drive. The IMMPI01 does not include hard disk storage.
Which processor modules are compatible with the IMMPI02?
The IMMPI02 interfaces directly with IMMFP03 Multi-Function Processors and INICT03 Computer Transfer Modules.
What is the reference price for the ABB IMMPI02?
Refurbished units show an observed market reference price of approximately $935.00 USD. This figure is an indicative reference price only and not a final quotation.
