PRODUCT INFORMATION
Product Overview
The Allen-Bradley 1746-HS is an IMC 110 motion controller module designed for the SLC 500 platform. It installs directly into a standard 1746 SLC 500 chassis slot to provide dedicated motion management. The unit executes precise position and velocity control for single-axis applications without overloading the main processor.
This single-axis motion controller draws 850 mA at 5 VDC typical current from the chassis backplane. It communicates across the local chassis backplane to coordinate axis profiles directly with SLC 500 processors. The module provides specialized motion command handling for industrial automation systems.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Module Type | Single-Axis Motion Controller |
|---|
| Control Modes | Position and velocity control |
|---|
| Axis Support | 1 motion axis |
|---|
| Chassis Compatibility | 1746 SLC 500 local chassis |
|---|
| Backplane Current | 850 mA at 5 VDC (typical) |
|---|
TECHNICAL INFORMATION
Features
- Dedicated IMC 110 architecture provides hardware-level execution of motion control commands.
- Single-axis control capability delivers dedicated position and velocity regulation.
- Direct backplane integration allows local communication with SLC 500 processors.
- Chassis-powered operation draws 850 mA at 5 VDC backplane current.
TECHNICAL INFORMATION
Applications
- Single-axis industrial positioning systems using 1746 SLC 500 hardware.
- Velocity regulation and point-to-point motion control in automated production machinery.
TECHNICAL INFORMATION
Connections / Interfaces
- Standard 1746 backplane interface connects into any compatible SLC 500 chassis slot.
TECHNICAL INFORMATION
Installation Guidelines
- Insert the module into an available slot within a 1746 SLC 500 local chassis.
- Verify that the chassis power supply accommodates the 850 mA backplane draw at 5 VDC.
- Turn off chassis power before seating or removing the module.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure position and velocity operating modes through your standard SLC 500 motion parameters.
TECHNICAL INFORMATION
Compatibility
- Compatible with Allen-Bradley 1746 SLC 500 local chassis assemblies.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with Allen-Bradley 1746 SLC 500 local chassis assemblies.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the Allen-Bradley 1746-HS?
The 1746-HS functions as an IMC 110 single-axis motion controller module for position and velocity control.
Which chassis hosts the 1746-HS module?
The module installs into a standard Allen-Bradley 1746 SLC 500 local chassis slot.
What is the typical reference price for the 1746-HS?
Market observations show reference pricing around $309.00 USD for used surplus. This is an indicative market reference only, not a final quotation.
