PRODUCT INFORMATION
Product Overview
The Allen-Bradley 2711P-K10C15D6 PanelView Plus CE 1000 Color Terminal Keypad functions within the PanelView family. It provides an operator interface with a 10.4-inch color display. Operators enter data and process commands through the integrated keypad interface. The terminal runs on an input supply voltage of 18 to 32 VDC. Internal memory capacity measures 128 MB for system runtime execution and local application storage.
This operator terminal communicates via ControlNet to connect with single or multiple automation controllers. It supports both scheduled and unscheduled traffic alongside redundant cabling configurations. ControlNet connectivity also enables symbolic CIP addressing when interfacing with ControlLogix systems. A dedicated Network Access port provides local network connection capabilities. Field replacement of the internal display illumination uses replacement backlight part number 2711P-RL10C.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Category | Panelviews |
|---|
| Product Line | Panelview Plus 1000 |
|---|
| Weight | 32.00 lbs (14.51 kg) |
|---|
| Display Size | 10.4 in. |
|---|
| Display Color | Color |
|---|
| Input Type | Keypad |
|---|
| Communication | ControlNet |
|---|
| Input Power | 18-32 VDC |
|---|
| Memory | 128 MB |
|---|
| Backlight | 2711P-RL10C |
|---|
| Communication Cable | 1747-KFC15A |
|---|
| Product Lifecycle Status* | Discontinued/Obsolete |
|---|
TECHNICAL INFORMATION
Features
- 10.4-inch color screen for graphical process visualization
- Keypad input interface for industrial plant floor data entry
- ControlNet communication interface supporting single and redundant cable configurations
- Support for scheduled and unscheduled controller data access
- Symbolic CIP addressing support for ControlLogix communication
- Local Network Access port for network maintenance and connection
- 128 MB internal application and system memory
- Field-serviceable backlight using part number 2711P-RL10C
TECHNICAL INFORMATION
Applications
- Machine-level human-machine interface for ControlLogix automation architectures
- Process visualization across scheduled ControlNet industrial networks
- Industrial monitoring stations requiring physical keypad tactile feedback
TECHNICAL INFORMATION
Connections / Interfaces
- ControlNet communication port supporting scheduled and unscheduled messaging
- Redundant cabling connections for ControlNet architecture
- Local Network Access port for direct programming and diagnostic connection
- DC power terminal block supporting 18 to 32 VDC input power
- Compatible with communication cable 1747-KFC15A
TECHNICAL INFORMATION
Installation Guidelines
- Verify the incoming direct current power source is between 18 and 32 VDC.
- Disconnect primary power before servicing the internal 2711P-RL10C backlight assembly.
- Route ControlNet cabling according to approved network topology and bend radius specifications.
TECHNICAL INFORMATION
Configuration Guidelines
- Develop and deploy graphic screens using FactoryTalk View Machine Edition software.
- Verify supported system firmware falls within the 3.13 to 4.48 operational range.
- Configure ControlNet scheduling parameters and symbolic CIP addressing for ControlLogix targets.
TECHNICAL INFORMATION
Compatibility
- Compatible with Allen-Bradley ControlLogix controllers over ControlNet networks
- FactoryTalk View Machine Edition development and runtime software
- Replacement backlight module 2711P-RL10C
- Communication cable assembly 1747-KFC15A
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- The 2711P-K10C15D6 terminal has reached discontinued and obsolete lifecycle status.
- Active production has ended, requiring sourcing through existing inventory or legacy stock.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with Allen-Bradley ControlLogix controllers over ControlNet networks FactoryTalk View Machine Edition development and runtime software Replacement backlight module 2711P-RL10C Communication cable assembly 1747-KFC15A
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What power supply does the 2711P-K10C15D6 require?
The terminal operates on a direct current supply range of 18 to 32 VDC.
Which communication protocols are integrated into the 2711P-K10C15D6?
The unit features ControlNet communication supporting scheduled, unscheduled, and redundant network paths alongside symbolic CIP addressing.
What is the replacement part number for the internal backlight?
The field-replaceable backlight assembly uses catalog part number 2711P-RL10C.
What is the lifecycle status of the 2711P-K10C15D6?
The 2711P-K10C15D6 operator interface terminal is classified as discontinued and obsolete by the manufacturer.
