PRODUCT INFORMATION
Product Overview
The Allen-Bradley 5069-L340ERP is a CompactLogix 5380 Process Controller designed for standard automation and PlantPAx 5.0 systems. This unit provides 4 MB of embedded user memory. It ships with a 2 GB 1784-SD2 Secure Digital card for non-volatile storage. The internal circuits feature conformal coating protection for harsh operating environments. It supports up to 31 local 5069 I/O modules and accommodates 256 motion axes.
Network connectivity includes two Gigabit Ethernet ports and one USB 2.0 full-speed port. The dual Ethernet ports support Linear, Star, and Device Level Ring network topologies. In Dual/IP operating mode, each Ethernet port operates with an independent IP address. In Linear/DLR mode, the device utilizes a single IP address. The controller handles an I/O packet capacity of 128,000 packets per second and up to 32 socket interfaces.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 5.00 lbs (2.27 kg) |
|---|
| Module Type | CompactLogix Process Controller |
|---|
| Application Memory | 4 Megabytes |
|---|
| Non-volatile memory | 2 GB via 1784-SD2 (ships with the controller) |
|---|
| Supported Ethernet/IP Network Topologies | Device Level Ring, Star, and Linear |
|---|
| Local I/O modules | 31 I/O modules |
|---|
| Communication Ports | 1 Type B 2.0 Full-Speed USB and 2 Ethernet/IP Ports |
|---|
| Communication rate, Ethernet | 10 Mbps / 100 Mbps / 1 Gbps |
|---|
| No. of Ethernet nodes | 90 |
|---|
| Integrated motion | Yes |
|---|
| No. of motion axes | 256 |
|---|
| No. of CIP drive | 20 |
|---|
| Communication rate, USB | 12 Mbps |
|---|
| Programming Languages | Sequential Function Chart, Function Block Diagram, Structured Text, and Ladder Diagram |
|---|
| Ports | 1 USB Port, 2 Ethernet/IP Ports |
|---|
| Dual/IP Operating Mode | Supported |
|---|
| Linear/DLR Operating Mode | Supported |
|---|
| Message Rate | 2000 Messages per Second |
|---|
| Ethernet/IP Nodes | 16 |
|---|
| Socket Interfaces | 32 |
|---|
TECHNICAL INFORMATION
Features
- Equipped with 4 MB of built-in application user memory.
- Ships with a 2 GB 1784-SD2 Secure Digital non-volatile memory card.
- Includes factory-applied conformal coating for protection in harsh and corrosive environments.
- Provides two Ethernet ports supporting 10 Mbps, 100 Mbps, and 1 Gbps full-duplex communication.
- Supports both Dual/IP and Linear/Device Level Ring operating network modes.
- Accommodates up to 31 local CompactLogix I/O modules across the backplane.
- Supports 256 motion axes and up to 20 CIP drive axes.
- Executes programs in Ladder Diagram, Structured Text, Function Block Diagram, and Sequential Function Chart.
TECHNICAL INFORMATION
Applications
- PlantPAx 5.0 distributed control system infrastructure using built-in process control templates.
- Integrated motion control applications using CIP drive synchronization over Ethernet/IP networks.
- Process automation skids deployed in industrial environments requiring conformally coated electronics.
- High-speed machine automation requiring segmented dual IP networking architecture.
TECHNICAL INFORMATION
Connections / Interfaces
- Two Ethernet/IP RJ45 ports supporting 10/100/1000 Mbps transmission rates.
- One USB 2.0 Type B port running at 12 Mbps for device configuration.
- One SD card slot populated with a 1784-SD2 memory card.
TECHNICAL INFORMATION
Installation Guidelines
- Verify MOD power supply voltage stays within the 18 to 32 V DC operating range.
- Ensure total MOD power current draw does not exceed the 450 mA rating.
- Maintain adequate panel spacing for convection cooling and wiring clearances.
TECHNICAL INFORMATION
Configuration Guidelines
- Select Dual/IP mode to assign independent network addresses to each physical Ethernet port.
- Select Linear/DLR mode when connecting the controller into a Device Level Ring.
- Deploy standard PlantPAx process templates in Studio 5000 for process loop programming.
TECHNICAL INFORMATION
Compatibility
- Supports Rockwell Automation PlantPAx 5.0 Distributed Control System platforms.
- Compatible with non-volatile cards 1784-SD1, 1784-SDHC8, 1784-SDHC32, and 9509-CMSDCD4.
- Integrates with Allen-Bradley 5069 Compact I/O expansion modules.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSSupports Rockwell Automation PlantPAx 5.0 Distributed Control System platforms. Compatible with non-volatile cards 1784-SD1, 1784-SDHC8, 1784-SDHC32, and 9509-CMSDCD4. Integrates with Allen-Bradley 5069 Compact I/O expansion modules.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What memory comes standard with the 5069-L340ERP?
The module includes 4 MB of user application memory and a pre-installed 2 GB 1784-SD2 SD card.
How many Ethernet ports are available on the 5069-L340ERP?
It provides two Ethernet ports supporting 10/100/1000 Mbps speeds in Dual/IP or Linear/DLR modes.
Does the 5069-L340ERP process module feature conformal coating?
Yes, this controller features factory-applied conformal coating for protection in harsh and corrosive environments.
