PRODUCT INFORMATION
Product Overview
The Allen-Bradley 5069-L350ERMS2K is a CompactLogix Safety Controller designed for functional safety and machine control applications. This controller provides a SIL 2 and PLd safety integrity level for critical processes. Memory allocation includes 5.0 MB for standard control tasks and 2.5 MB dedicated to safety logic. It supports up to 120 EtherNet/IP nodes for distributed machine automation across industrial networks.
Conformal coating shields internal circuitry against moisture, airborne dust, and environmental contamination. Network connectivity features two 1 Gbps Ethernet ports alongside a dedicated USB 2.0 Type B programming interface. Integrated motion capabilities accommodate control for up to 24 axes across coordinated drive systems. Local expansion supports up to 31 local I/O modules directly installed on the backplane assembly.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 5.00 lbs (2.27 kg) |
|---|
| Safety Rating | SIL 2 / PLd |
|---|
| Standard User Memory | 5.0 MB |
|---|
| Safety User Memory | 2.5 MB |
|---|
| Conformal Coating | Yes |
|---|
| EtherNet/IP Nodes | 120 nodes |
|---|
| Ethernet Ports | 2 ports (Dual-port 1 Gbps) |
|---|
| USB Port | 1 USB 2.0 Type B port |
|---|
| Integrated Motion | 24 axes of Integrated Motion |
|---|
| Local I/O Capacity | 31 local I/O modules |
|---|
| Sensor Voltage AC | 0–240V AC |
|---|
| Sensor Voltage DC | 0–32V DC |
|---|
TECHNICAL INFORMATION
Features
- SIL 2 and PLd safety capability for integrated safety applications
- 5.0 MB standard user memory with 2.5 MB dedicated safety user memory
- Support for up to 120 EtherNet/IP communication nodes
- Dual-port 1 Gbps Ethernet interfaces for high-speed network communication
- Integrated motion control supporting up to 24 motion axes
- Expansion capacity supporting up to 31 local I/O modules
- Factory-applied conformal coating for protection in harsh operating environments
- Sensor input compatibility spanning 0 to 240V AC and 0 to 32V DC
TECHNICAL INFORMATION
Applications
- Industrial machinery requiring SIL 2 or PLd functional safety monitoring
- Multi-axis coordinated motion control systems across packaging or converting equipment
- Distributed EtherNet/IP machine automation architectures in harsh environments
TECHNICAL INFORMATION
Connections / Interfaces
- Dual 1 Gbps Ethernet ports provide high-speed network connectivity
- One USB 2.0 Type B port enables direct programming and diagnostic connections
- Local bus supports direct connection for up to 31 local I/O modules
TECHNICAL INFORMATION
Installation Guidelines
- Mount the controller securely in an enclosure with appropriate thermal management
- Verify proper grounding and shield termination before applying system power
- Connect 5069 local expansion I/O modules directly along the backplane interlock
TECHNICAL INFORMATION
Configuration Guidelines
- Configure standard logic and dedicated safety routines using Studio 5000 Logix Designer
- Assign system communication settings across up to 120 EtherNet/IP field nodes
- Configure coordinated drive parameters for up to 24 integrated motion axes
TECHNICAL INFORMATION
Compatibility
- Compatible with Allen-Bradley 5069 Compact I/O expansion modules
- Interoperates with EtherNet/IP networked drives and distributed field devices
TECHNICAL INFORMATION
Compliance and Certifications
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with Allen-Bradley 5069 Compact I/O expansion modules Interoperates with EtherNet/IP networked drives and distributed field devices
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What safety rating does the Allen-Bradley 5069-L350ERMS2K provide?
The 5069-L350ERMS2K controller provides functional safety compliance rated at SIL 2 and PLd.
How much memory is available in the 5069-L350ERMS2K?
The controller contains 5.0 MB of standard user memory and 2.5 MB of dedicated safety user memory.
How many EtherNet/IP nodes and motion axes does this controller support?
The controller supports up to 120 EtherNet/IP nodes and up to 24 integrated motion axes.
Does the 5069-L350ERMS2K include conformal coating?
Yes, the K suffix indicates that this controller is equipped with factory-applied conformal coating.
