PRODUCT INFORMATION
Product Overview
The Bently Nevada 3300XL extension cable1 330130-045-00-00 is a Standard Extension Cable for the 3300 XL 8mm series. This cable connects proximity probe assemblies to Proximitor sensors in transducer systems. The complete system measures static position and dynamic vibration on industrial machinery. It produces an output voltage proportional to the distance between the probe and conductive surface.
The standard 5-meter system complies with API 670 Fourth Edition mechanical design and linear range requirements. It also satisfies standard specifications for measurement accuracy and temperature stability. Individual probes, extension cables, and Proximitor sensors offer full interchangeability across systems. This interchangeability removes any requirement for component matching or bench calibration routines. The cable option provides 4.5 metres of standard cable length.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Length | 4.5 metres |
|---|
| Cable Length Option | 4.5 metres (14.8 feet) |
|---|
| Connector Protector and Cable Option | Standard cable |
|---|
| Agency Approval Option | Not required |
|---|
TECHNICAL INFORMATION
Features
- Complies with API 670 Fourth Edition standards in complete 5-meter system installations.
- Enables complete interchangeability among probes, extension cables, and Proximitor sensors.
- Eliminates the requirement for component matching or bench calibration.
- Provides a 4.5-metre standard cable configuration.
- Supports extended temperature range application requirements.
TECHNICAL INFORMATION
Applications
- Fluid-film bearing machinery monitoring.
- Dynamic vibration measurements on rotating shafts.
- Static position measurements on machine shafts.
- Keyphasor reference and rotational speed measurements.
- Compression system monitoring applications.
TECHNICAL INFORMATION
Connections / Interfaces
- Connects between an eddy current probe and a Proximitor sensor.
TECHNICAL INFORMATION
Installation Guidelines
- Connect the cable between the proximity probe and the Proximitor sensor.
- Ensure the total system length matches the required 5-meter configuration.
TECHNICAL INFORMATION
Compatibility
- Fully interchangeable with 3300 XL 8 mm proximity transducer system components.
- Compatible with transducer system components from other non-3300 XL series.
TECHNICAL INFORMATION
Compliance and Certifications
- API 670 Fourth Edition compliant in standard 5-meter system configurations.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSFully interchangeable with 3300 XL 8 mm proximity transducer system components. Compatible with transducer system components from other non-3300 XL series.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the function of the Bently Nevada 330130-045-00-00 extension cable?
It connects proximity probes to Proximitor sensors in 3300 XL 8 mm transducer systems.
Does the 330130-045-00-00 require bench calibration during installation?
No calibration is required. System components are interchangeable without matching or bench calibration.
What is the length of this 3300 XL extension cable?
The cable length is 4.5 metres, which equals 14.8 feet.
What industry standard does this transducer cable system meet?
The standard 5-meter system fully complies with the API 670 Fourth Edition standard.
