PRODUCT INFORMATION
Product Overview
The General Electric DS200RTBAG3AHC is a Mark V Relay Terminal Board. It installs as an optional board within compatible turbine control drive cabinets. The board supports management and control operations for gas, steam, and wind turbine drive systems. It operates within GE Mark V Speedtronic turbine control architectures.
This board features ten relays controlled directly by pilot relays or remotely by the user. It includes 52 terminal points dedicated to input and output connections. Terminal points support Form C contact configurations including normally open, common, and normally closed points. Two stab connectors provide positive and negative pluggable circuit control power across the assembly.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Instruction Manual | GEI-100167 |
|---|
| PCB Coating | Normal Coating |
|---|
TECHNICAL INFORMATION
Features
- Ten on-board relays operated via pilot relays or remote user command.
- Fifty-two terminal points dedicated to field input and output wiring.
- Form C contact wiring points for relay circuits such as K20.
- CPH and CPN stab connectors supplying positive and negative control power.
- Integrated voltage suppression utilizing capacitors, resistors, and diodes.
TECHNICAL INFORMATION
Applications
- General Electric Mark V Speedtronic turbine control systems.
- Industrial drive cabinet assemblies for gas, steam, and wind turbines.
TECHNICAL INFORMATION
Connections / Interfaces
- Stab connectors CPH and CPN deliver positive and negative pluggable circuit control power.
- Power distributes across pluggable circuits C1PL through C5PL and Y9PL through Y37PL.
- Fifty-two terminal points provide landing locations for user input and output wiring.
- Terminal groups interface with relay contacts including normally open, common, and normally closed positions.
TECHNICAL INFORMATION
Installation Guidelines
- Disconnect all electrical power from the drive cabinet before servicing the board.
- Stop the motor using the control panel and execute standard orderly shutdown routines.
- Remove the three-phase fuses from the main power supply to isolate high energy circuits.
- Follow documentation guidelines outlined in General Electric instruction manual GEI-100167.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric Mark V turbine control drive cabinets.
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- The DS200RTBAG3AHC represents a three-fold revision version of the parent DS200RTBAG3A board.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with General Electric Mark V turbine control drive cabinets.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the GE DS200RTBAG3AHC?
The General Electric DS200RTBAG3AHC is an optional Relay Terminal Board for Mark V drive cabinets. It provides ten relays and 52 terminal points for turbine control I/O circuits.
Which connectors provide control power on the DS200RTBAG3AHC?
Stab connectors CPH and CPN provide control power. CPH supplies positive voltage and CPN supplies negative voltage to internal circuits.
What safety steps are required prior to handling the board?
Operators must shut down the drive using standard control panel procedures. Technicians must then remove three-phase power supply fuses to eliminate high-energy electrical risks.
