PRODUCT INFORMATION
Product Overview
The General Electric IC200CHS001 is a VersaMax Input/Output Carrier designed for modular automation assemblies. This unit features a barrier-style termination system with 36 individual screw terminals. It supports up to 32 field input/output points. In addition, the carrier provides four dedicated power and common connections.
The carrier operates at working voltage levels reaching up to 264 Volts AC. It withstands voltage transients up to 300 Volts AC without signal disruption. Each input/output point accommodates a maximum current of 2 Amperes. The auxiliary power connections support loads up to 8 Amperes.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 1.00 lbs (0.45 kg) |
|---|
| UPC | 699252966952 |
|---|
| Wiring Termination Style | Barrier style |
|---|
| Number of Terminals | 36 barrier-style terminals |
|---|
| Rated Current Per Point | 2 Amperes (maximum) |
|---|
| Voltage Rating | 264 Volts AC (maximum) |
|---|
| Maximum Number of Inputs/Outputs | 32 input/output points and 4 common/power connections |
|---|
| Voltage Transients | 300 Volts AC (maximum) |
|---|
| Rated Current Per Power Connection | 8 Amperes (maximum) |
|---|
| Mounting Type | 7.5 millimeters x 35 millimeters DIN rail mount |
|---|
| Mounting Orientation | Horizontal |
|---|
| Compatible Wire Type | Solid or stranded copper wires |
|---|
| Applicable Wire Size | 22 American Wire Gauge (AWG) |
|---|
| Recommended Terminal Torque | 0.37 to 0.5 foot-pounds |
|---|
TECHNICAL INFORMATION
Features
- Accommodates up to 32 input/output channels alongside four power and common connections.
- Features 36 barrier-style terminal connections for field wiring termination.
- Supports operating line voltages up to 264 Volts AC.
- Withstands transient voltage spikes up to 300 Volts AC.
- Rated for 2 Amperes maximum per point and 8 Amperes per power connection.
- Mounts directly on standard 7.5 mm x 35 mm DIN rail in a horizontal orientation.
TECHNICAL INFORMATION
Applications
- VersaMax I/O module field wiring termination.
- Control panel distributed I/O installations.
TECHNICAL INFORMATION
Connections / Interfaces
- Field connections use 36 barrier-style screw terminals.
- Compatible with 22 AWG solid or stranded copper conductors.
- Includes 32 signal terminals and four power or common points.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the carrier horizontally on a 35 mm by 7.5 mm DIN rail.
- Tighten all terminal screws to a torque between 0.37 and 0.5 foot-pounds.
- Use only solid or stranded copper wiring rated for 22 AWG.
- Verify correct polarities across all 32 I/O lines and four power connections prior to energization.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric VersaMax I/O modules.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with General Electric VersaMax I/O modules.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the maximum current rating for the IC200CHS001?
Each I/O point supports up to 2 Amperes. The power connections handle up to 8 Amperes maximum.
What DIN rail size is required to mount the IC200CHS001 carrier?
The carrier mounts onto a standard 7.5 mm by 35 mm DIN rail in a horizontal orientation.
What wire size and torque are specified for terminal connections?
The barrier terminals accept 22 AWG solid or stranded copper wire tightened to 0.37 to 0.5 foot-pounds.
