PRODUCT INFORMATION
Product Overview
The General Electric IC660EBS101 is an Electronic Terminal Block ISO Terminal Block within the Genius I/O series. This electronics assembly provides eight isolated input and output circuits. The circuits are organized into four distinct pairs. It features a block-to-block isolation rating of 1500 Volts. Operating voltage ranges from 93 to 132 VAC or 105 to 132 VDC. The assembly operates at a frequency between 47 and 63 Hz.
Diagnostic indicators include Unit OK and I/O Enabled LEDs located on the logic side. Each individual I/O circuit also features a dedicated status LED. Maximum heat dissipation equals 16 Watts with eight active inputs. Heat dissipation reaches 45.6 Watts with eight outputs at 2 Amps. The operating temperature spans from 0 to 60 degrees Celsius. Storage temperature ranges from -40 to 100 degrees Celsius.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Block to Block Isolation | 1500 V |
|---|
| Circuit LEDs | On logic side of the switch |
|---|
| Frequency | 47 to 63 Hz |
|---|
| Humidity | 5 to 95 percent (non-condensing) |
|---|
| Maximum Ripple | 10 percent |
|---|
| Operating Temperature | 0 to 60 degrees Celsius |
|---|
| Product Line | Genius I-O |
|---|
| Size | 22.44 x 8.89 x 10.00 cm |
|---|
| Storage Temperature | -40 to 100 degrees Celsius |
|---|
| Weight | 1.75 lbs (0.79 kg) |
|---|
TECHNICAL INFORMATION
Features
- Provides eight isolated input and output circuits arranged in four pairs.
- Features a block-to-block isolation rating of 1500 Volts.
- Accepts power supplies of 93 to 132 VAC or 105 to 132 VDC.
- Includes Unit OK and I/O Enabled logic-side status LEDs.
- Contains individual circuit LEDs located on the logic side.
- Dissipates up to 16 Watts for inputs and 45.6 Watts for outputs.
TECHNICAL INFORMATION
Installation Guidelines
- Maintain ambient operating temperatures between 0 and 60 degrees Celsius.
- Keep relative humidity within 5 to 95 percent non-condensing.
- Provide ventilation capable of dissipating up to 45.6 Watts of thermal energy.
TECHNICAL INFORMATION
Compatibility
- Compatible with GE Fanuc Genius bus controllers.
- Operates with QBIM and PCIM interface modules.
- Compatible with IC660BBS100, IC660BBS101, and IC660CBS100 base blocks.
- Connects with a hand-held monitor for baud rate and redundancy configuration.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with GE Fanuc Genius bus controllers. Operates with QBIM and PCIM interface modules. Compatible with IC660BBS100, IC660BBS101, and IC660CBS100 base blocks. Connects with a hand-held monitor for baud rate and redundancy configuration.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the General Electric IC660EBS101?
The IC660EBS101 is an isolated Genius I/O electronics assembly managing eight isolated input and output circuits.
Which base blocks work with the IC660EBS101?
The unit is compatible with IC660BBS100, IC660BBS101, and IC660CBS100 base blocks.
What are the operating voltage limits for the IC660EBS101?
It operates from 93 to 132 VAC or 105 to 132 VDC.
How are baud rate and redundancy configured on this module?
A hand-held monitor is used to configure baud rate and redundancy settings on the module.
