PRODUCT INFORMATION
Product Overview
The General Electric IC670ALG630 is an Analog Input Module within the Field Control distributed I/O family. This module features eight independent input channels for analog signal processing. Internal power consumption for the unit is rated at 195 mA during routine operation. Integrated green and amber status LEDs deliver visual operational feedback directly on the unit.
Operating temperature specifications for the module range from 0 °C to 55 °C. Storage temperature ratings extend between -40 °C and 85 °C across inactive periods. The module functions in non-condensing relative humidity environments between 5% and 95%. Installation limits permit deployment at altitudes up to 1000 meters above sea level. The total unit weight measures 1.00 lbs or 0.45 kg.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 1.00 lbs (0.45 kg) |
|---|
| Number of Channels | 8 independent input channels |
|---|
| Internal Power Consumption | 195 mA |
|---|
| Status Indicators | LED |
|---|
| LED Colors | Green, Amber |
|---|
| Min. Operating Temperature | 0 °C |
|---|
| Max. Operating Temperature | 55 °C |
|---|
| Min. Storage Temperature | -40 °C |
|---|
| Max. Storage Temperature | 85 °C |
|---|
| Installation Altitude | 1000 m |
|---|
| Min. Relative Humidity | 5% (Non-Condensing) |
|---|
| Max. Relative Humidity | 95% (Non-Condensing) |
|---|
TECHNICAL INFORMATION
Features
- Provides eight independent analog input channels for concurrent signal acquisition.
- Operates with an internal power consumption rating of 195 mA.
- Incorporates green and amber LED indicators for local diagnostic monitoring.
- Supports operating environments ranging from 0 °C up to 55 °C.
- Rated for operation in non-condensing relative humidity between 5% and 95%.
- Designed for installation at altitudes reaching up to 1000 meters.
TECHNICAL INFORMATION
Installation Guidelines
- Install the module in a suitable protective enclosure to maintain environmental specifications.
- Verify operating ambient temperatures remain strictly between 0 °C and 55 °C.
- Observe the 1000-meter maximum altitude rating during site engineering.
- Maintain ambient relative humidity within 5% to 95% without moisture condensation.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
How many input channels are supported on the IC670ALG630?
The General Electric IC670ALG630 supports eight independent analog input channels.
What is the internal power consumption of the IC670ALG630?
The module has a rated internal power consumption of 195 mA.
What are the operating temperature limits for the IC670ALG630?
The operating temperature range for the IC670ALG630 is 0 °C to 55 °C.
What visual indicators are present on the IC670ALG630?
The module features LED status indicators with green and amber colors.
