PRODUCT INFORMATION
Product Overview
The General Electric IC698PSD300 is a PACSystems RX7i power supply. This module operates on a nominal 24 VDC input. Its operational input voltage range spans 18 to 30 VDC. The unit delivers up to 300 Watts of total output power. Maximum input power reaches 550 Watts under full operating conditions.
DC output is distributed across three separate power rails. It supplies 50 Amps at 5 VDC. It provides 10 Amps at 12 VDC. An additional rail delivers 4 Amps at -12 VDC. Cold start inrush current reaches up to 100 Amps maximum. A minimum ride-through duration of 15 milliseconds maintains operation during brief voltage drops. Internal protection safeguards against overvoltage, overcurrent, and overtemperature faults.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 6.25 lbs (2.83 kg) |
|---|
| Nominal Input Voltage | 24 VDC |
|---|
| Input Voltage Range | 18 to 30 VDC |
|---|
| Total Output Power | 300 Watts |
|---|
| Input Power (Max) | 550 Watts |
|---|
| 5 VDC Output Rail | 50 Amps |
|---|
| 12 VDC Output Rail | 10 Amps |
|---|
| Cold Start Inrush Current | 100 Amps max |
|---|
| Ride-Through Time | 15 ms minimum |
|---|
| Isolation Test Rating | 1500 VAC for 1 minute |
|---|
| Integral Protection | Overvoltage, overcurrent, overtemperature |
|---|
| Status Indicators | Output OK (green) and Fault (red) LEDs |
|---|
| Operating Temperature | 0°C to +60°C |
|---|
TECHNICAL INFORMATION
Features
- Delivers 300 Watts of total DC output power across system rails.
- Operates from an input range of 18 to 30 VDC with 24 VDC nominal.
- Supplies 50 Amps at 5 VDC, 10 Amps at 12 VDC, and 4 Amps at -12 VDC.
- Maintains rack operation with a minimum ride-through duration of 15 milliseconds.
- Withstands a cold start inrush current of up to 100 Amps maximum.
- Features integrated protection against overvoltage, overcurrent, and overtemperature conditions.
- Includes front-panel LED indicators for Output OK and Fault status.
- Meets an isolation test rating of 1500 VAC tested for one minute.
TECHNICAL INFORMATION
Applications
- PACSystems RX7i rack power delivery in industrial automation setups.
- Control rack installations operating from plant 24 VDC power distribution networks.
TECHNICAL INFORMATION
Installation Guidelines
- Operate the module within ambient temperatures from 0°C to +60°C.
- Provide adequate ventilation to prevent exceeding internal overtemperature limits.
- Verify that input voltage polarity and levels stay between 18 and 30 VDC.
TECHNICAL INFORMATION
Compatibility
- General Electric PACSystems RX7i controller racks.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSGeneral Electric PACSystems RX7i controller racks.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What are the output rail ratings for the IC698PSD300?
The unit supplies 50 Amps at 5 VDC. It provides 10 Amps at 12 VDC and 4 Amps at -12 VDC.
What input voltage range does the IC698PSD300 support?
The nominal input is 24 VDC. The operational input range extends from 18 to 30 VDC.
What do the status LEDs on the module indicate?
A green LED signals that the output functions properly. A red LED illuminates when a fault occurs.
What is the ride-through duration of the IC698PSD300?
The module provides a minimum ride-through time of 15 milliseconds during power interruptions.
