PRODUCT INFORMATION
Product Overview
The General Electric IC754CSF06CTD is a dedicated QuickPanel operator panel designed for human-machine interface applications. It operates on a direct-current power supply ranging from 12 to 30 VDC. The terminal runs an embedded Intel XScale PXA255 processor with a 300 MHz clock speed. Visual output is delivered on a 6-inch color Thin Film Transistor liquid crystal display. This screen provides a native graphic resolution of 320 by 240 pixels.
User input is processed through an integrated resistive touchscreen interface. Internal system memory includes 64 MB flash memory and 32 MB dynamic random-access memory. It also features 512 KB static random-access memory with battery retention and a 512 KB bootloader partition. Connectivity options include an Ethernet port, RS-232 and RS-485 serial interfaces, and two USB ports. The terminal runs the Windows CE operating system to support standard industrial monitoring utilities.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 6.63 lbs (3.01 kg) |
|---|
| Display Size | 6" |
|---|
| Processor | Intel XScale PXA255 |
|---|
| Clock Speed | 300 Mhz |
|---|
| Display Resolution | 320 x 240 pixels |
|---|
| Display Type | Colored Thin Film Transistor (TFT) |
|---|
| Operator Input | Resistive, 12 bit |
|---|
| Integral Memory | FLASH 64 MB SRAM 512KB (power off retention is the life of the battery) DRAM 32 MB ROM 512 KB (Boot loader) |
|---|
| Interface | One (1) Ethernet interface, One (1) Serial EIA232C/EIA485, DP25S combo port, One (1) RS232 port Two (2) USB Interfaces. |
|---|
| Operating System (OS) | Windows CE Operating System. |
|---|
| Power Supply | 12 to 30 VDC |
|---|
| Real Power | 24 W |
|---|
| Connector | Phoenix Contact, 1777992 |
|---|
| Display Color | Color |
|---|
| Input Type | Touchscreen |
|---|
| Communication | RS232 and RS485 |
|---|
| Input Power | 12 - 30 VDC |
|---|
| Memory | 32 MB |
|---|
| Communication Cable | HMI-CAB-CS3 |
|---|
| Product Lifecycle Status* | Discontinued/Obsolete |
|---|
TECHNICAL INFORMATION
Features
- Features an Intel XScale PXA255 processor running at a clock rate of 300 MHz.
- Includes a 6-inch color TFT display with a resolution of 320 x 240 pixels.
- Provides resistive touchscreen input for machine interaction and data entry.
- Equipped with 64 MB flash memory and 32 MB dynamic random-access memory.
- Contains 512 KB battery-backed SRAM and a 512 KB boot loader partition.
- Provides 10/100 Mbps Ethernet networking with auto-negotiation capability.
- Offers dedicated RS-232 and combo RS-232/RS-485 serial communication ports.
- Operates from a direct-current nominal input voltage range of 12 to 30 VDC.
TECHNICAL INFORMATION
Applications
- Operator interface terminals for industrial automation and machinery monitoring.
- Supervisory display and parameter adjustment on PLC networks.
- Point-to-point serial communication links to dedicated machine controllers.
TECHNICAL INFORMATION
Connections / Interfaces
- One 10/100 Mbps auto-negotiation Ethernet port for plant network connectivity.
- One DB25 combo port supporting RS-232C and RS-485 multi-drop communication.
- One dedicated RS-232 serial communication interface for point-to-point links.
- Two USB host interfaces for connecting external peripherals like mice and keyboards.
- Phoenix Contact connector model 1777992 for main power supply wiring.
TECHNICAL INFORMATION
Installation Guidelines
- Supply clean DC power between 12 and 30 VDC to terminal connections.
- Ensure power wiring connects via the specified Phoenix Contact terminal block.
- Maintain adequate enclosure ventilation to dissipate nominal 24 W thermal power.
- Ground the unit properly to prevent electrical noise on serial links.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure project runtime files using Proficy View-Machine Edition software.
- Establish initial communications using the compatible HMI-CAB-CS3 programming cable.
- Set Ethernet network parameters inside the Windows CE operating system environment.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric PLC architectures and controllers.
- Interconnects with programming systems using the HMI-CAB-CS3 serial communication cable.
- Communicates with third-party automation controllers over RS-232 and RS-485 protocols.
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- The IC754CSF06CTD operator panel is classified as discontinued and obsolete by the manufacturer.
- Replacement units and spare parts are sourced through surplus industrial automation suppliers.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with General Electric PLC architectures and controllers. Interconnects with programming systems using the HMI-CAB-CS3 serial communication cable. Communicates with third-party automation controllers over RS-232 and RS-485 protocols.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What input voltage is required for the GE IC754CSF06CTD?
The IC754CSF06CTD requires an input supply voltage between 12 and 30 VDC, consuming 24 W power.
What operating system runs on the IC754CSF06CTD operator panel?
The IC754CSF06CTD runs the Windows CE operating system and features an Intel XScale PXA255 processor.
What communication ports are available on the IC754CSF06CTD?
It features one Ethernet interface, one RS-232 port, one combo RS-232/RS-485 port, and two USB ports.
What software is used to program the IC754CSF06CTD?
Configuration and runtime projects are developed using Proficy View-Machine Edition software.
What is the commercial pricing for the IC754CSF06CTD?
Pricing varies by supplier and unit condition; published figures represent indicative market reference pricing only, not final quotations.
