PRODUCT INFORMATION
Product Overview
The General Electric IC754VBL06CTD is a QuickPanel Human Machine Interface (HMI) terminal. It provides plant operators with real-time process visualization and machine control capabilities. The terminal features a 6-inch color TFT display with a resolution of 320 by 240 pixels. It includes an analog resistive touch screen for direct operator interaction. A 300 MHz Intel XScale processor powers the operator panel. The unit runs on the Microsoft Windows CE operating system.
The IC754VBL06CTD operates on an input power supply between 12 and 30 VDC. Internal memory architecture includes 64 MB flash memory, 512 KB SRAM, and 64 MB DRAM. Users can expand memory capacity via a 100-pin DIMM slot. Compatible memory modules include IC754ACC32MEM and IC754ACC64MEM. Networking is supported through two RJ45 Ethernet ports and serial communication interfaces. Configuration and application designs are deployed through Proficy Machine Edition software.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 3.75 lbs (1.70 kg) |
|---|
| Display Size | 6" |
|---|
| Display Color | Color |
|---|
| Processor | Intel XScale PXA250, 300 Mhz |
|---|
| Input Type | Touchscreen |
|---|
| Display Resolution | 320 x 240 pixels |
|---|
| Communication | RS232 and RS485 |
|---|
| Display Type | Colored Thin Film Transistor (TFT) |
|---|
| Input Power | 12 - 30 VDC |
|---|
| Operator Input | Resistive, 12 bit |
|---|
| Integral Memory | FLASH64 MB SRAM 512KB (power off retention is the life of the battery) DRAM 64 MB |
|---|
| Memory | 32 MB |
|---|
| Memory expansion slot | 100 pin DIMM |
|---|
| Communication Cable | HMI-CAB-CS3 |
|---|
| Memory Type | SDRAM |
|---|
| Compatible memory modules | IC754ACC32MEM (32MB); IC754ACC64MEM (64 MB) |
|---|
| Interface | Two (2) Ethernet interface, One (1) Serial EIA232C/EIA485, DP25S combo port, One (1) RS232 port Two (2) USB Interfaces |
|---|
| Product Lifecycle Status* | Discontinued/Obsolete |
|---|
| Operating System (OS) | Windows CE Operating System |
|---|
| Power Supply | 12 to 30 VDC |
|---|
TECHNICAL INFORMATION
Features
- Equipped with a 6-inch color TFT display supporting 320 by 240 pixel resolution.
- Utilizes an Intel XScale 300 MHz processor for application execution.
- Contains dual RJ45 10/100 Mbps Ethernet communication ports.
- Includes serial interface ports supporting RS-232 and RS-485 communication protocols.
- Powered via a standard 12 to 30 VDC input supply.
- Supports memory expansion through a dedicated 100-pin DIMM slot.
TECHNICAL INFORMATION
Applications
- Industrial machine automation and direct equipment monitoring.
- Plant floor process interaction and operator parameter adjustments.
- Supervisory control interfacing with automated production machinery.
TECHNICAL INFORMATION
Connections / Interfaces
- Two RJ45 Ethernet ports for 10/100 Mbps network communication.
- One serial RS-232 port for direct communication links.
- One DP25S combo serial port supporting RS-232 and RS-485 communication.
- Two USB interface ports for external connections.
- Supports connection using the HMI-CAB-CS3 communication cable.
TECHNICAL INFORMATION
Installation Guidelines
- Connect the unit to an approved 12 to 30 VDC power source.
- Ensure all communication cables are securely connected prior to power application.
- Allow sufficient clearance around the terminal enclosure for adequate thermal dissipation.
TECHNICAL INFORMATION
Configuration Guidelines
- Create and download operator interface screens using Proficy Machine Edition software.
- Configure Ethernet network parameters directly within the Windows CE operating system.
TECHNICAL INFORMATION
Compatibility
- Compatible with memory expansion module IC754ACC32MEM.
- Compatible with memory expansion module IC754ACC64MEM.
- Supports communication via cable model HMI-CAB-CS3.
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- The IC754VBL06CTD is categorized as a discontinued and obsolete product.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with memory expansion module IC754ACC32MEM. Compatible with memory expansion module IC754ACC64MEM. Supports communication via cable model HMI-CAB-CS3.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the screen resolution of the IC754VBL06CTD?
The terminal has a 6-inch color TFT display with a resolution of 320 by 240 pixels.
What operating system runs on the General Electric IC754VBL06CTD?
The terminal runs on the Microsoft Windows CE operating system.
What input power is required for the IC754VBL06CTD?
The IC754VBL06CTD operates on a DC power supply ranging from 12 to 30 VDC.
Can internal memory be expanded on the IC754VBL06CTD?
Yes, memory expands via a 100-pin DIMM slot using IC754ACC32MEM or IC754ACC64MEM modules.
