PRODUCT INFORMATION
Product Overview
The General Electric IC755CBS06RDA is a Quickpanel+ terminal from the QuickPanel series. This operator interface features a 5.7-inch color TFT display with resistive touchscreen support. It operates on a Freescale i.MX5351 ARM Cortex A8 microprocessor running at 1 Gigahertz. The unit includes 512 MB of RAM, 256 MB flash memory, and 512 KB SRAM. External storage expansion is supported through an integrated SD card slot.
The terminal runs on the Microsoft Windows Embedded Compact 7 operating system. It requires a 24 VDC power supply and consumes up to 15 Watts. Communication interfaces include one 10/100BaseT Ethernet port, one RS-232 port, and three USB ports. Panel installation requires a cutout opening measuring 183.5 by 128.5 millimeters. Standard 75 by 75 millimeter VESA mounting bases are also supported.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 2.25 lbs (1.02 kg) |
|---|
| Display Size | 6 inches |
|---|
| Touchscreen | Yes |
|---|
| Microprocessor | ARM A8 |
|---|
| RAM | 512 megabytes |
|---|
| Input Voltage | 24 Volts DC |
|---|
| Maximum Power Input | 15 Watts |
|---|
| Ethernet Ports | 1 |
|---|
TECHNICAL INFORMATION
Features
- 5.7-inch TFT LCD color display with 320 x 240 QVGA resolution.
- Resistive analog touchscreen interface with 375 nits brightness rating.
- 1 GHz Freescale i.MX5351 ARM Cortex A8 microprocessor architecture.
- Memory allocation of 512 MB RAM and 256 MB flash storage.
- Integrated 10/100BaseT Ethernet connection and one RS-232 serial interface.
- Three USB ports configured as two host connections and one device connection.
TECHNICAL INFORMATION
Connections / Interfaces
- One 10/100BaseT Ethernet port for network communications.
- One RS-232 serial communication port.
- Two USB host ports for peripheral integration.
- One USB device port for direct programming connection.
- One SD card slot for external memory expansion.
- One microphone-in port and one line-out audio port.
TECHNICAL INFORMATION
Installation Guidelines
- Prepare an enclosure panel cutout measuring 183.5 mm by 128.5 mm.
- Allow proper enclosure clearance for outer dimensions of 192 x 137 x 36 millimeters.
- Secure the unit using panel mounting clamps or 75 x 75 mm VESA mounts.
- Connect a regulated 24 VDC power source rated for at least 15 Watts.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What display specifications does the IC755CBS06RDA terminal feature?
The terminal features a 5.7-inch color TFT LCD screen. It supports 320 x 240 QVGA resolution and 65,536 colors.
What are the input power requirements for the IC755CBS06RDA?
The IC755CBS06RDA operates on a nominal 24 Volts DC supply. Maximum power consumption is 15 Watts.
Which operating system runs on the IC755CBS06RDA terminal?
The unit runs on the Microsoft Windows Embedded Compact 7 operating system.
