PRODUCT INFORMATION
Product Overview
The General Electric IC755CSS15CDA is a QuickPanel Human Machine Interface (HMI). It runs on a 1 GHz Freescale i.MX535 processor built on ARM Cortex A8 architecture. The terminal incorporates a 15-inch projected capacitive display screen. It supports multi-touch operator input and provides an SVGA resolution of 1024 by 768 pixels. Dedicated 2D and 3D graphics processing units accelerate visual display rendering. A Vector floating point coprocessor and NEON SIMD media accelerator support processing operations. The device operates the Microsoft Windows Embedded Compact 7 operating system.
Integral hardware memory includes 1 GB SDRAM and 512 MB SLC NAND flash. An onboard 512 KB battery-backed SDRAM retains critical process data during power interruptions. The terminal operates using direct-current input power rated at 12 to 24 VDC. Maximum power consumption during full operation reaches 30 Watts. Natural convection maintains operating temperatures between 0 and 55 degrees Celsius. The front panel features a manufacturer monogram bezel designed for industrial enclosures. A mounting gasket enables secure installation even within compact control panel cutouts.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 13.44 lbs (6.10 kg) |
|---|
| Screen Size | 15 inches |
|---|
| Resolution | 1024 x 768 pixels |
|---|
| Processor | Freescale i.MX535 1GHz based on ARM Cortex A8 |
|---|
| Screen Type | Capacitive |
|---|
| Display Size | 15" |
|---|
| Serial Port | 2 |
|---|
| Display Resolution | 1024 x 768 SVGA |
|---|
| USB Port | 2 |
|---|
| Display Type | Projected Capacitive Display |
|---|
| Audio Out | 1 |
|---|
| Operator Input | Multi-touch |
|---|
| Operating System | Windows 7 |
|---|
| Integral Memory | 1 GB SDRAM; 512 MB SLC NAND FLASH; 512 KB Battery Backed SDRAM |
|---|
| Temperature | 0 to 55 degrees Celsius |
|---|
| Communication Interface | Two (2) Ethernet interface; One (1) RS232; One (1) RS485; |
|---|
| Power Consumption | 30 Watts |
|---|
| USB Ports | 2x USB 2.0 (Type-A); 1x USB 2.0 (Mini Type-B) |
|---|
| Operating System (OS) | Windows CE Operating System version 7 |
|---|
| Power Supply | 12 / 24 VDC |
|---|
| Status Indicators | Tri-color LED (Amber/Green/Red); On-board Buzzer |
|---|
| Functionalities | HMI; PLC; Process controller; Data Historian; Gateway |
|---|
| Programming languages | Ladder Diagram (LD); Function Block Diagram (FBD); Structured Text (ST); Instruction List (IL); Sequential Function Chart (SFC) |
|---|
| Bezel | With manufacturer monogram |
|---|
TECHNICAL INFORMATION
Features
- 15-inch projected capacitive display supporting multi-touch operator interaction.
- Freescale i.MX535 1 GHz processor based on ARM Cortex A8 architecture.
- Integrated memory architecture with 1 GB SDRAM and 512 MB SLC NAND flash.
- Battery-backed 512 KB SDRAM retains operational data through power cycles.
- Dual 10/100 Mbps Ethernet ports provide plant network integration.
- Dedicated serial interfaces include one RS-232 port and one RS-485 port.
- Three USB interfaces include two Type-A ports and one Mini Type-B port.
- Onboard diagnostic hardware provides a tri-color LED indicator and an audible buzzer.
TECHNICAL INFORMATION
Applications
- Industrial automation process monitoring and visual operator control.
- Supervisory data aggregation across plant automation networks.
- Point-to-point and multi-drop serial interfacing with industrial controllers.
TECHNICAL INFORMATION
Connections / Interfaces
- Two 10/100 Mbps Ethernet ports for local-area network communications.
- One 5-pin RS-232 serial port for point-to-point controller connections.
- One RS-485 serial port supporting multi-device daisy-chain networks.
- Two USB 2.0 Type-A ports for mouse, keyboard, or flash drive connection.
- One USB 2.0 Mini Type-B port for external peripheral connection.
- One audio output port for external sound devices.
- One Secure Digital (SD) card slot for expanded external memory storage.
TECHNICAL INFORMATION
Installation Guidelines
- Install the terminal inside a protective enclosure using the supplied mounting gasket.
- Provide adequate clearance around the chassis for natural convection cooling airflow.
- Maintain ambient operating temperatures within the specified 0 to 55 degrees Celsius range.
- Connect direct-current electrical power within the rated 12 to 24 VDC range.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure control programs using Ladder Diagram, Function Block Diagram, or Structured Text.
- Instruction List and Sequential Function Chart programming formats are fully supported.
- Set up network communication parameters and remote access within Windows Embedded Compact 7.
TECHNICAL INFORMATION
Compatibility
- Interfaces with automation equipment using RS-232 and RS-485 communication protocols.
- Supports standard USB peripherals including external keyboards, mice, and flash storage drives.
TECHNICAL INFORMATION
Compliance and Certifications
- ATEX Zone 2
- CE (EN 60950-1, EN 61000-6-4, EN 61000-6-2)
- CUL Mark - US/CAN Zone 2
- FCC Part 15 Class A
- IP65F (JEM 1030)
- NEMA 4X
- RoHS
- UL 60950
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSInterfaces with automation equipment using RS-232 and RS-485 communication protocols. Supports standard USB peripherals including external keyboards, mice, and flash storage drives.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What display technology is used in the IC755CSS15CDA?
The terminal features a 15-inch projected capacitive display. It provides SVGA resolution of 1024 by 768 pixels with multi-touch operation.
What communication interfaces are present on the IC755CSS15CDA?
The unit provides two Ethernet ports, one RS-232 port, and one RS-485 port. It also includes three USB ports.
What operating system runs on the IC755CSS15CDA?
The interface executes the Microsoft Windows Embedded Compact 7 operating system on an ARM Cortex A8 processor.
What electrical power input does the IC755CSS15CDA require?
The unit operates on 12 to 24 VDC input power. Maximum power consumption during operation is 30 Watts.
