PRODUCT INFORMATION
Product Overview
The Schneider Electric 140CPS12400 is a redundant Power Supply Module designed for the Modicon Quantum automation platform. It delivers a regulated 5.1 V DC output to the backplane to support installed system modules. The unit accepts input voltages of either 115 V AC or 230 V AC. It provides continuous power availability in redundant configurations.
The module draws an input current of 1100 mA at 115 V AC and 600 mA at 230 V AC. It is rated for an apparent power output of 130 VA. Circuit protection is provided by an associated 2 A slow-blow fuse. Visual monitoring is supported via a front-panel green PWR OK indicator.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Ambient Operating Temperature | 0…60 °C |
|---|
| Ambient Storage Temperature | -40…85 °C |
|---|
| Associated Fuse Rating | 2 A, slow-blow |
|---|
| EAN | 3595861126657 |
|---|
| GTIN | 3595861126657 |
|---|
| Input Current | 1100 mA at 115 V and 600 mA at 230 V |
|---|
| Input Voltage | 115/230 V AC |
|---|
| Inrush Current | 19 A at 230 V, 38 A at 115 V |
|---|
| Local Signalling | 1 green "PWR OK" LED |
|---|
| Operating Altitude | 5000 m |
|---|
| Output Voltage | 5.1 V DC |
|---|
| Power Supply Type | Redundant |
|---|
| Product Line | Modicon Quantum |
|---|
| Rated Power | 130 VA |
|---|
| Relative Humidity | 95% without condensation |
|---|
| Weight | 2.00 lbs (0.91 kg) |
|---|
TECHNICAL INFORMATION
Features
- Redundant power supply architecture for high-availability Modicon Quantum backplanes.
- Dual AC input capability supporting 115 V AC or 230 V AC operation.
- Regulated 5.1 V DC output voltage for rack-mounted modules.
- Maximum input current draw of 1100 mA at 115 V AC and 600 mA at 230 V AC.
- Slow-blow 2 A associated fuse rating for circuit surge protection.
- Front-panel green PWR OK LED for immediate visual operational status.
TECHNICAL INFORMATION
Applications
- Modicon Quantum programmable logic controller backplane power distribution.
- High-availability process automation architectures requiring redundant power supplies.
- Industrial control installations operating under 115 V AC or 230 V AC utility lines.
TECHNICAL INFORMATION
Connections / Interfaces
- AC line power input terminal connections supporting 115 V AC and 230 V AC.
- Dedicated Modicon Quantum backplane connector routing the 5.1 V DC output bus.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the module directly into an assigned slot of a Modicon Quantum backplane.
- Verify that input line supply matches 115 V AC or 230 V AC specifications before energizing.
- Maintain adequate ventilation clearance to support the rated 0 to 60 °C operating temperature range.
- Ensure the slow-blow 2 A associated fuse is verified before commissioning.
TECHNICAL INFORMATION
Configuration Guidelines
- Verify that the power consumption of all rack modules does not exceed backplane ratings.
- Pair with a secondary compatible supply when establishing redundant power operation.
- Monitor the green PWR OK LED on startup to confirm 5.1 V DC bus stability.
TECHNICAL INFORMATION
Compatibility
- Schneider Electric Modicon Quantum backplanes and rack assemblies.
- Modicon Quantum controller and I/O modules operating on 5.1 V DC backplane power.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSSchneider Electric Modicon Quantum backplanes and rack assemblies. Modicon Quantum controller and I/O modules operating on 5.1 V DC backplane power.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the Schneider Electric 140CPS12400?
The module provides a regulated 5.1 V DC power source to Modicon Quantum backplanes in redundant configurations.
What AC input voltages does the 140-CPS-124-00 support?
The module operates from either 115 V AC or 230 V AC power sources.
What is the market reference price for the 140CPS12400?
Observed market reference pricing is approximately $935.00 USD. This figure is an indicative reference price only and not a final quotation.
