PRODUCT INFORMATION
Product Overview
The Schneider Electric 140CRP93200 is a Modicon Quantum RIO Networking Module functioning as a head-end adaptor. It provides remote input and output communication across distributed Quantum system racks. The module achieves a data transmission rate of 1544 Mbit/s over 75 Ohm coaxial media. It addresses up to 64 input words and 64 output words per individual remote drop. This setup supports fast data streams within distributed automation systems.
Backplane electrical operation requires a bus current of 750 mA when operating across two channels. Power dissipation is rated at 3W for the two-channel configuration. The unit features an isolation voltage of 500V DC between the coaxial center conductor and ground. It functions in ambient operating temperatures from 0°C to 60°C. Storage temperatures range from -40°C to 85°C with non-condensing relative humidity up to 95%.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Bus Current Requirement | 750 mA for 2 channels |
|---|
| Cable Type | 75 Ohm coaxial cable |
|---|
| Connectors | 2 connectors |
|---|
| Dynamic Rating | 35 dB |
|---|
| EAN | 3595861133761 |
|---|
| I/O Words per Drop | 64 input words, 64 output words |
|---|
| Isolation Voltage | 500V DC for coaxial center and ground |
|---|
| Non-Condensing Relative Humidity | 95% |
|---|
| Operating Temperature Range | 0°C to 60°C |
|---|
| Power Dissipation | 3W for 2 channels |
|---|
| Product | RIO head-end adaptor |
|---|
| Product Line | Modicon Quantum |
|---|
| Redundant Cable | Supported |
|---|
| Storage Temperature Range | -40°C to 85°C |
|---|
| Transmission Rate | 1544 Mbit/s |
|---|
| Weight | 2.00 lbs (0.91 kg) |
|---|
TECHNICAL INFORMATION
Features
- High-speed transmission rate of 1544 Mbit/s over 75 Ohm coaxial cable.
- Dual-connector interface supports redundant cable network topologies.
- Addresses up to 64 input words and 64 output words per remote drop.
- Low power dissipation of 3W across two active channels.
- Electrical isolation rating of 500V DC between coaxial center conductor and ground.
- Dynamic rating of 35 dB helps maintain high signal integrity.
TECHNICAL INFORMATION
Applications
- Remote input and output management across distributed Modicon Quantum architectures.
- High-speed coaxial data communication between head-end controllers and remote drops.
- Dual-cable redundant communication links in Quantum PLC network topologies.
TECHNICAL INFORMATION
Connections / Interfaces
- Two connectors accommodate 75 Ohm coaxial cable connections.
- Dual connections support redundant cabling to prevent network disruption.
- Module connects directly to the Modicon Quantum backplane.
TECHNICAL INFORMATION
Installation Guidelines
- Insert the module into an available slot in the Modicon Quantum backplane.
- Ensure power is disconnected before installing or removing the module.
- Secure 75 Ohm coaxial cables firmly to the front panel connectors.
- Operate the device in environments between 0°C and 60°C.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure drops to address no more than 64 input words and 64 output words each.
- Verify that 75 Ohm coaxial cabling meets network termination impedance specifications.
TECHNICAL INFORMATION
Compatibility
- Compatible with Modicon Quantum series backplanes and controllers.
- Connects to Modicon Quantum remote I/O drop adaptors.
- Operates over standard 75 Ohm coaxial cable networks.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with Modicon Quantum series backplanes and controllers. Connects to Modicon Quantum remote I/O drop adaptors. Operates over standard 75 Ohm coaxial cable networks.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the 140CRP93200 module?
The 140CRP93200 functions as a RIO head-end adaptor for Modicon Quantum systems. It manages data communication with remote drops.
What transmission rate does the 140CRP93200 support?
The module supports a data transmission rate of 1544 Mbit/s over 75 Ohm coaxial cables.
Does the 140CRP93200 support redundant cabling?
Yes. The module provides two connectors to support redundant coaxial cable networks.
What is the reference price for the 140CRP93200 module?
Observed market reference pricing is approximately $595 USD for refurbished units. This figure is an indicative market reference only, not a final quotation.
