Product Overview
The Woodward 9907-014 is a 2301A series Load Sharing & Speed Control unit configured specifically as a speed control module. This device governs prime mover rotational speed across industrial operating installations. The hardware operates on a nominal 24 VDC supply with an acceptable input span of 18 to 40 VDC. It supplies a dedicated 0 to 200 mA output designed to drive an external actuator.
Speed sensing occurs via magnetic pickup signals providing an alternating current input between 1.0 and 30 VAC. The unit features a low-voltage sheet metal chassis designed for direct panel or surface mounting. Its physical enclosure measures 8.625 inches wide, 7.25 inches high, and 2.5 inches deep. The assembly tolerates storage temperatures from -40 to +70 °C and maintains formal CSA certification.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input Voltage | 18-40 VDC (24 VDC Nominal) |
|---|
| Actuator Output | 0-200 mA |
|---|
| Speed Sensing Input | Magnetic Pickup (MPU) 1.0 to 30 VAC |
|---|
| Enclosure Type | Low Voltage (LV) Chassis |
|---|
| Chassis Material | Sheet Metal |
|---|
| Mounting Configuration | Chassis / Surface Mounted |
|---|
| Dimensions | 8.625 x 7.25 x 2.5 in |
|---|
| Storage Temperature | -40 to +70 °C |
|---|
| Certifications | CSA Certified |
|---|
TECHNICAL INFORMATION
Features
- Configured specifically as a dedicated speed control unit.
- Accepts magnetic pickup inputs from 1.0 to 30 VAC.
- Delivers a 0 to 200 mA actuator drive output.
- Operates on an 18 to 40 VDC power input.
- Constructed with a sheet metal low-voltage chassis.
- Designed for chassis surface-mount panel installation.
TECHNICAL INFORMATION
Applications
- Prime mover speed governing systems.
- Engine rotational speed control using 0 to 200 mA actuators.
- Industrial equipment installations utilizing magnetic pickup speed sensing.
TECHNICAL INFORMATION
Connections / Interfaces
- Terminals for magnetic pickup speed input from 1.0 to 30 VAC.
- Actuator output terminals providing 0 to 200 mA drive current.
- Power supply terminal connections for 18 to 40 VDC input.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the sheet metal chassis securely to a flat interior panel surface.
- Allow sufficient clearance surrounding the chassis for wiring and air circulation.
- Confirm input voltage is within 18 to 40 VDC before applying power.
- Use shielded wiring on the magnetic pickup input to suppress signal noise.
TECHNICAL INFORMATION
