PRODUCT INFORMATION
Product Overview
The ABB 07KT97-ARCNET is an Advant OCS Controller designed for Advant Controller 31 systems. This unit features 480 kB of user program memory. It operates using a 24 VDC power supply. Integrated networking interfaces include an ARCNET network coupler and a CS31 fieldbus line. Two RS-232 serial ports support programming devices and serial data transmission. The hardware manages embedded digital and analog I/O directly.
This programmable logic controller provides comprehensive input and output capacity for automation cells. It contains 24 digital inputs and 16 digital outputs rated at 24 VDC and 0.5 A. Eight configurable digital channels function as either inputs or outputs. Eight analog inputs and four analog outputs support continuous process instrumentation. The unit weighs 2.85 kg and operates from 0 to 55 degrees Celsius.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| ABB product ID | GJR5253000R0260 |
|---|
| Controller family | Advant Controller 31 / AC31 |
|---|
| User program memory | 480 kB |
|---|
| Supply voltage | 24 VDC |
|---|
| Serial ports | 2 × RS-232 |
|---|
| System bus | CS31 |
|---|
| Network coupler | ARCNET |
|---|
| Digital inputs | 24 |
|---|
| Digital outputs | 16 |
|---|
| Configurable digital inputs/outputs | 8 |
|---|
| Analog inputs | 8 |
|---|
| Analog outputs | 4 |
|---|
| Digital output rating | 24 VDC / 0.5 A |
|---|
TECHNICAL INFORMATION
Features
- Provides 480 kB of user program memory for sequence and control execution.
- Integrates an onboard ARCNET network coupler and a CS31 system bus connection.
- Features two RS-232 serial communication ports for external device interfacing.
- Supplies 24 digital inputs, 16 digital outputs, and 8 configurable digital channels.
- Delivers 8 analog input channels and 4 analog output channels for process instrumentation.
- Provides digital transistor outputs rated at 24 VDC and 0.5 A.
TECHNICAL INFORMATION
Applications
- Advant Controller 31 automation architectures requiring integrated analog and digital I/O.
- Industrial machinery and plant automation segments linked via ARCNET communication networks.
- Distributed control installations communicating across standard CS31 fieldbus lines.
TECHNICAL INFORMATION
Connections / Interfaces
- Onboard ARCNET network coupler port for local industrial network communication.
- Integrated CS31 system bus interface for remote expansion communication.
- Two RS-232 serial interfaces for programming connections and peripheral communication.
- Dedicated connection terminals for 24 VDC power and integrated I/O wiring.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the controller within a protective enclosure suited for the industrial operating environment.
- Ensure adequate cabinet ventilation to maintain operating temperatures between 0 and 55 degrees Celsius.
- Verify correct 24 VDC supply voltage and polarity before connecting power to the controller.
TECHNICAL INFORMATION
Configuration Guidelines
- Assign unique ARCNET network node identifiers prior to putting the controller into service.
- Configure the eight assignable digital channels in software as inputs or outputs.
- Transfer program logic and settings using programming tools via the RS-232 serial ports.
TECHNICAL INFORMATION
Compatibility
- Advant Controller 31 (AC31) distributed automation system architectures.
- CS31 remote fieldbus networks and compatible distributed I/O units.
- Industrial automation networks utilizing compatible ARCNET communication segments.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSAdvant Controller 31 (AC31) distributed automation system architectures. CS31 remote fieldbus networks and compatible distributed I/O units. Industrial automation networks utilizing compatible ARCNET communication segments.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the ABB 07KT97-ARCNET controller?
It serves as a programmable logic controller within ABB AC31 systems, featuring onboard ARCNET, CS31, and integrated I/O.
What I/O channels are integrated into the 07KT97-ARCNET hardware?
The controller contains 24 digital inputs, 16 digital outputs, 8 configurable digital channels, 8 analog inputs, and 4 analog outputs.
What communication interfaces are available on the 07KT97-ARCNET?
The controller features an ARCNET network coupler, a CS31 fieldbus interface, and two RS-232 serial communication ports.
What is the reference market price for the ABB 07KT97-ARCNET?
Observed market reference pricing is approximately $965.00 USD for refurbished units. This figure represents indicative market reference pricing only and is not a final quotation. Final pricing depends on condition, stock availability, and delivery terms.
