PRODUCT INFORMATION
Product Overview
The ABB 6240BP10411 is a MOD 300 Source I/O Block 16 Circuits complete unit. It operates on an 18 to 30 VDC power supply. The unit provides 16 discrete circuits. Each circuit can be configured independently as an input or an output. The block sources direct current to connected field loads.
This complete unit includes both the electronics assembly and the terminal assembly. Field wiring terminals accommodate one 12 AWG or two 14 AWG conductors. Built-in diagnostics monitor for short circuits, overloads, and failed switches. The block also detects no-load conditions and circuit overtemperature states. Electrical isolation between blocks is rated at 1500 V.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Configuration | 24 VDC source, complete unit |
|---|
| Discrete I/O circuits | 16; individually configured as inputs or outputs |
|---|
| Operating voltage | 18–30 VDC for the 24 VDC block |
|---|
| Supply ripple maximum | 10% |
|---|
| Operational current excluding loads | 150 mA typical; 300 mA maximum |
|---|
| Supply dropout time | 10 ms |
|---|
| Block-to-block isolation | 1500 V |
|---|
| Insulation resistance | 2.2 Mohm minimum |
|---|
| Terminal wiring | One 12 AWG conductor or two 14 AWG conductors |
|---|
| Weight | 1.8 kg |
|---|
| Operating temperature | 0–60 °C |
|---|
| Storage temperature | -40 to +100 °C |
|---|
| Relative humidity | 5–95%, non-condensing |
|---|
| Input impedance | 1.8 kohm for the 24 VDC block |
|---|
| Input processing time | 1.7 ms typical plus selected filter delay |
|---|
| Input filter | 5–100 ms selectable |
|---|
| Output current per circuit | 2 A steady state |
|---|
| Output inrush current | 10 A for up to 10 ms |
|---|
| Total block output current | 15 A at 35 °C |
|---|
| Output off-state leakage | 1.0 mA |
|---|
| Output turn-on delay | 1 ms maximum |
|---|
| Output diagnostics | Short circuit, overload, no load, failed switch and overtemperature |
|---|
TECHNICAL INFORMATION
Features
- Provides 16 discrete circuits individually configurable as inputs or outputs.
- Delivers 2 A steady-state output current per circuit.
- Handles output inrush currents up to 10 A for 10 ms.
- Supports a total block output load of 15 A at 35 °C.
- Offers selectable input filter times from 5 to 100 ms.
- Provides integrated diagnostics for overload, short circuit, and overtemperature conditions.
TECHNICAL INFORMATION
Applications
- MOD 300 distributed control system discrete field device interfacing.
- Process automation requiring mixed discrete DC inputs and outputs.
- Switching discrete field loads such as coils, indicators, and actuators.
TECHNICAL INFORMATION
Connections / Interfaces
- Terminals 1 through 4 provide connections for the TRIO block field bus.
- Screw terminals accept one 12 AWG or two 14 AWG field wires.
- Unit OK and I/O Enabled LEDs show general block operating status.
- Individual load-side LED indicators display status for each discrete circuit.
TECHNICAL INFORMATION
Installation Guidelines
- Operate the block within an ambient temperature range of 0 to 60 °C.
- Verify that power supply ripple remains below 10 percent.
- Ensure total block output current does not exceed 15 A at 35 °C.
- Account for maximum heat dissipation of 68.8 W during enclosure thermal planning.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure each of the 16 circuits independently as an input or an output.
- Select input filter delay times between 5 and 100 ms.
- Enable no-load diagnostics when connected output loads exceed 50 mA.
TECHNICAL INFORMATION
Compatibility
- Compatible with ABB MOD 300 architectures using TRIO and Genius field bus networks.
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- Part number 6240BP10411 designates the complete 24 VDC source unit.
- The replacement electronics assembly alone is part number 6240BP10421.
- The replacement terminal assembly alone is part number 6240BP10431.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with ABB MOD 300 architectures using TRIO and Genius field bus networks.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the configuration of the ABB 6240BP10411 block?
The 6240BP10411 is a complete 24 VDC source unit. It provides 16 discrete circuits configurable as inputs or outputs.
What are the output ratings for the 6240BP10411 block?
Each circuit supplies 2 A steady-state current. Maximum total block output current is 15 A at 35 °C.
What diagnostic features are supported on the block?
The block detects short circuits, overloads, and failed switches. It also flags open wires, no-load conditions, and overtemperature.
What is the block-to-block electrical isolation rating?
The unit provides 1500 V electrical isolation between blocks. Minimum insulation resistance is 2.2 megohms.
What input filter delay settings are selectable?
Input filter times can be configured from 5 to 100 ms. Typical base input processing time is 1.7 ms.
