PRODUCT INFORMATION
Product Overview
The ABB ACS580-01-014A-4+R700 3AXD50000820238 is an ACS580 series AC drive designed for industrial motor speed control. It operates on a three-phase input voltage ranging from 380 to 500 V AC at 50/60 Hz. The drive provides an apparent power output of 12 kVA. It is built in an R2 frame size designed for wall-mounting installations. Operating standby loss is rated at 14 W.
This AC drive supports dual output ratings for industrial loads. Light-overload operation provides up to 10 HP with an output current of 14 A. Heavy-duty use delivers 7.5 HP with an output current of 11 A. The unit features an enclosure rated for NEMA Type 1, UL Type 1, and IP21 protection. It operates with an IE2 efficiency classification at ambient temperatures up to 40 °C.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input Voltage (Uin) | 380 - 500 V AC, 3-phase |
|---|
| Frequency | 50/60 Hz |
|---|
| Frame Size | R2 |
|---|
| Enclosure / Protection | NEMA Type 1, UL Type 1, IP21 |
|---|
| Mounting Type | Wall-mounting |
|---|
| Apparent Power Output | 12 kVA |
|---|
| Output Current, Light-Overload Use (UL) | 14 A |
|---|
| Output Power, Light-Overload Use (UL) | 10 HP |
|---|
| Output Current, Heavy-Duty Use (UL) | 11 A |
|---|
| Output Power, Heavy-Duty Use (UL) | 7.5 HP |
|---|
| Efficiency Level | IE2 |
|---|
| Standby Loss | 14 W |
|---|
| Temperature Rating | Up to 40 °C (104 °F) |
|---|
TECHNICAL INFORMATION
Features
- Designed for three-phase 380 to 500 V AC industrial power systems.
- Delivers 10 HP output at 14 A for light-overload operating profiles.
- Supplies 7.5 HP output at 11 A under heavy-duty loading conditions.
- Features an R2 frame size configured for standard wall mounting.
- Meets IE2 efficiency classification with low standby losses of 14 W.
- Enclosure provides IP21, NEMA Type 1, and UL Type 1 physical protection.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the R2 frame vertically against a flat wall surface.
- Maintain adequate clear airflow around the unit during installation.
- Ensure ambient operating temperatures do not exceed 40 °C.
- Connect incoming three-phase AC wiring rated between 380 and 500 V.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What are the output power ratings for the ABB ACS580-01-014A-4+R700?
The drive supplies 10 HP at 14 A for light overload and 7.5 HP at 11 A for heavy duty.
What is the enclosure protection rating for part number 3AXD50000820238?
The drive enclosure is rated for IP21, NEMA Type 1, and UL Type 1 compliance.
What is the reference price for this ACS580 drive unit?
Market observations show reference pricing near $1,680.00 USD. This figure is indicative market reference pricing only and is not a final quotation.
