Product Overview
The ABB ACS580-01-023A-4+K469 3AXD50000748594 is an ACS580 series wall-mounting AC Drive. It operates on a three-phase input voltage range from 380 to 500 V AC at 50/60 Hz. This unit utilizes an R2 frame size designed with a UL Type 1 and IP21 enclosure rating. The drive delivers 15 HP output power for light-overload service and 10 HP for heavy-duty operation.
For field connectivity, this drive configuration includes integrated EtherCAT communication capability via the designated factory option code. It features a Standard Assistant Control Panel mounted on the unit for local operation and diagnostics. Rated output current reaches 23 A in light-overload conditions and 14 A under heavy-duty loading. Wall-mounting brackets facilitate direct installation into industrial electrical enclosures or control rooms.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input Voltage | 380 - 500 V AC, 3-phase |
|---|
| Frequency | 50 / 60 Hz |
|---|
| Output Current, Light-Overload Use (UL) | 23 A |
|---|
| Output Power, Light-Overload Use (UL) | 15 HP |
|---|
| Output Current, Heavy-Duty Use (UL) | 14 A |
|---|
| Output Power, Heavy-Duty Use (UL) | 10 HP |
|---|
| Frame Size | R2 |
|---|
| Mounting Type | Wall-mounting |
|---|
| Enclosure | UL Type 1 / IP21 |
|---|
| Control Panel | Standard Assistant Control Panel |
|---|
| Communication | EtherCAT |
|---|
TECHNICAL INFORMATION
Features
- Delivers 15 HP light-overload and 10 HP heavy-duty output power ratings.
- Supports three-phase input supplies from 380 V AC to 500 V AC at 50/60 Hz.
- Features an integrated EtherCAT communication interface option.
- Includes a Standard Assistant Control Panel for local drive monitoring and setup.
- Housed in an R2 frame size with UL Type 1 and IP21 protection.
TECHNICAL INFORMATION
Connections / Interfaces
- EtherCAT communication interface supported via factory option code +K469.
- Standard Assistant Control Panel interface for operator parameter access.
- Three-phase AC power input terminals rated for 380 to 500 V AC.
TECHNICAL INFORMATION
Installation Guidelines
- Designed for direct wall-mounting in vertical orientation.
- Install in environments conforming to UL Type 1 and IP21 environmental standards.
- Ensure adequate clearance around the R2 frame size for proper ventilation airflow.
