Product Overview
The ABB ACS580-01-022A-6+K470 3AXD50000510733 is an ACS580 series AC drive. This wall-mounted unit requires a 3-phase input of 525 to 600 V AC at 50 or 60 Hz. The drive features an R3 physical frame size. Environmental protection conforms to IP21 and NEMA Type 1 ratings. The integrated +K470 option provides dedicated Ethernet POWERLINK communication.
The unit provides dual operating load ratings for industrial operation. Light overload output delivers 20 HP or 15 kW with 22 A continuous current. Heavy-duty output supplies 15 HP or 11 kW with 17 A continuous current. The drive controls output frequency and voltage for three-phase motor loads. Network connectivity allows direct digital supervision over industrial Ethernet POWERLINK buses.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input Voltage | 525 - 600 V AC |
|---|
| Phase | 3-phase |
|---|
| Frequency | 50 / 60 Hz |
|---|
| Output Current (Light Overload) | 22 A |
|---|
| Output Current (Heavy Duty) | 17 A |
|---|
| Output Power (Light Overload) | 20 HP (15 kW) |
|---|
| Output Power (Heavy Duty) | 15 HP (11 kW) |
|---|
| Communication | Ethernet POWERLINK |
|---|
| Enclosure Rating | IP21 / NEMA Type 1 |
|---|
| Frame Size | R3 |
|---|
| Mounting Type | Wall-mounted |
|---|
TECHNICAL INFORMATION
Features
- Delivers 20 HP (15 kW) output at 22 A for light overload demands.
- Provides 15 HP (11 kW) output at 17 A for heavy-duty duties.
- Accepts 3-phase 525 to 600 V AC input power at 50 or 60 Hz.
- Includes factory-fitted +K470 Ethernet POWERLINK fieldbus communication.
- Constructed in an R3 frame size configured for wall-mounted installation.
- Housed in an IP21 / NEMA Type 1 protective enclosure.
TECHNICAL INFORMATION
Connections / Interfaces
- Three-phase AC power input terminals for 525 to 600 V AC line connections.
- Three-phase AC motor output terminals.
- Ethernet POWERLINK communication interface port.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the unit vertically on a flat, non-flammable wall surface.
- Allow adequate clearance around the R3 frame for proper cooling airflow.
- Verify supply voltage matches the 525 to 600 V AC input specification.
- Ground the equipment properly before connecting main line power.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure operating parameters according to light overload or heavy-duty load demands.
- Set communication parameters for node identification on the Ethernet POWERLINK network.
TECHNICAL INFORMATION
Compatibility
- Integrates with automation controllers supporting Ethernet POWERLINK network communication.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSIntegrates with automation controllers supporting Ethernet POWERLINK network communication.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the output power rating of the ABB ACS580-01-022A-6+K470?
The drive delivers 20 HP (15 kW) for light overload and 15 HP (11 kW) for heavy-duty operation.
What communication protocol does the +K470 option provide?
The +K470 option integrates an Ethernet POWERLINK communication interface for network control.
What is the indicative reference price for part number 3AXD50000510733?
The observed market reference price is $4,389.00 USD. Figures are indicative market reference pricing only and are not a final quotation.
