PRODUCT INFORMATION
Product Overview
The ABB ACS580-01-06A0-4 3AUA0000204808 is an ACS580 series AC drive. It is designed for wall mounting in industrial environments. This unit operates from a three-phase AC input supply. The specified input voltage range is 380 to 480 VAC. It delivers controlled variable-speed power to three-phase electric motors. The drive is manufactured in an R1 frame size.
The drive provides continuous electrical ratings for light-duty and heavy-duty operation. Under light-duty conditions, it supplies 6 A output current and 3 hp power. For heavy-duty applications, it supplies 4 A output current and 3 hp power. The maximum output current capacity is 8.6 A. The unit features an environmental enclosure rated at UL Type 1 and IP21.
Physical dimensions include a height of 14.69 inches. Chassis width measures 4.82 inches and depth is 8.78 inches. The complete drive has a net weight of 11 lb. This AC drive integrates into standard motor control cabinets and wall stations. The compact R1 chassis provides standard mounting provisions for secure wall installation. Its UL Type 1 and IP21 enclosure rating protects internal electronic components from basic airborne debris.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Input phases | 3 |
|---|
| Input-voltage range | 380–480 VAC |
|---|
| Maximum output current | 8.6 A |
|---|
| Light-duty output current | 6 A |
|---|
| Light-duty output power | 3 hp |
|---|
| Heavy-duty output current | 4 A |
|---|
| Heavy-duty output power | 3 hp |
|---|
| Frame size | R1 |
|---|
| Enclosure | UL Type 1 / IP21 |
|---|
| Mounting | Wall mounting |
|---|
| Product height | 14.69 in |
|---|
| Product width | 4.82 in |
|---|
| Product depth | 8.78 in |
|---|
| Product net weight | 11 lb |
|---|
TECHNICAL INFORMATION
Features
- Accepts a three-phase input supply from 380 to 480 VAC.
- Delivers light-duty continuous motor output of 6 A and 3 hp.
- Provides heavy-duty continuous motor output of 4 A and 3 hp.
- Supplies a peak maximum output current reaching 8.6 A.
- Built in an R1 frame size enclosure for direct wall mounting.
- Meets UL Type 1 and IP21 enclosure ingress protection standards.
- Compact footprint measuring 14.69 inches high by 4.82 inches wide.
- Chassis depth measures 8.78 inches with total weight of 11 lb.
TECHNICAL INFORMATION
Connections / Interfaces
- Three-phase AC power input terminals support line voltages between 380 and 480 VAC.
- Variable-frequency three-phase output connections supply power directly to the motor.
- Enclosure openings permit structured power cabling entry through the base of the frame.
- Grounding terminals provide dedicated connection points for electrical bonding.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the R1 frame drive vertically on a flat, solid wall surface.
- Use mechanical fasteners appropriate for the drive net weight of 11 lb.
- Maintain clear spacing around the chassis to allow unobstructed cooling airflow.
- Verify three-phase incoming voltage remains within the 380 to 480 VAC range.
- Install the unit in a dry environment matching UL Type 1 and IP21 specifications.
TECHNICAL INFORMATION
Compliance and Certifications
- UL Type 1 enclosure rating for indoor protection.
- IP21 ingress protection rating against vertical water drops and touch hazards.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What input voltage does the ABB ACS580-01-06A0-4 drive require?
The drive requires a three-phase input supply between 380 and 480 VAC.
What are the output ratings for the 3AUA0000204808 drive?
Light duty provides 6 A and 3 hp. Heavy duty provides 4 A and 3 hp. Maximum current is 8.6 A.
What is the physical frame size and weight of this unit?
The drive uses an R1 frame size. It weighs exactly 11 lb.
What enclosure rating does the ACS580-01-06A0-4 feature?
The drive enclosure is rated for UL Type 1 and IP21 indoor conditions.
What is the reference price for the ABB 3AUA0000204808 AC drive?
Pricing varies by condition and availability. Figures are indicative market reference pricing only and are not a final quotation.
