PRODUCT INFORMATION
Product Overview
The ABB TU810V1 3BSE013230R1 is an Advant-800xA compact module termination unit designed for industrial I/O signal distribution. This termination unit provides two rows of eight signal terminals accommodating up to 16 individual process channels. It secures field wiring directly into the control architecture while maintaining organized termination points for S800 I/O modules.
The unit supports maximum operating voltages up to 50 V. Each channel handles a maximum continuous current of 2 A. The overall process connection supports up to 5 A total current. Screw terminals accept solid conductors from 0.2 to 4 mm² and stranded wire from 0.2 to 2.5 mm².
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB |
|---|
| Model | TU810V1 |
|---|
| Part Number | 3BSE013230R1 |
|---|
| Product Type | Compact Module Termination Unit |
|---|
| Number of Channels | 16 channels |
|---|
| Terminal Configuration | 2 x 8 signal terminals |
|---|
| Voltage Rating | 50 V |
|---|
| Maximum Current per Channel | 2 A |
|---|
| Maximum Current for Process Connection | 5 A |
|---|
| Wire Size (Solid) | 0.2–4 mm² (24–12 AWG) |
|---|
| Wire Size (Stranded) | 0.2–2.5 mm² (24–12 AWG) |
|---|
| Ingress Protection | IP20 |
|---|
TECHNICAL INFORMATION
Features
- Compact module termination unit layout with two rows of eight signal terminals.
- Provides connection points for up to 16 process channels.
- Rated for operating voltages up to 50 V.
- Supports up to 2 A continuous current per individual channel.
- Maximum current rating of 5 A for process connection.
- IP20 ingress protection rating against solid foreign objects.
TECHNICAL INFORMATION
Applications
- ABB Advant-800xA control systems.
- S800 I/O process field wiring termination.
- Industrial automation and distributed control signal routing.
TECHNICAL INFORMATION
Connections / Interfaces
- Two rows of eight terminal positions for field signal wiring.
- Screw clamp terminals accepting 24 to 12 AWG wire sizes.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the unit inside a suitable protective cabinet to maintain environmental integrity beyond IP20.
- Verify conductor cross-sections conform to 0.2–4 mm² solid or 0.2–2.5 mm² stranded ratings.
- Ensure total process current does not exceed the 5 A design limit.
TECHNICAL INFORMATION
Compatibility
- ABB Advant-800xA control systems.
- Compatible with standard ABB S800 I/O modules designed for compact MTU bases.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSABB Advant-800xA control systems. Compatible with standard ABB S800 I/O modules designed for compact MTU bases.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the ABB TU810V1 3BSE013230R1?
The TU810V1 3BSE013230R1 serves as a 16-channel compact module termination unit for connecting field wiring to S800 I/O modules.
What are the electrical ratings for each channel on the TU810V1?
The unit supports up to 50 V with a maximum current limit of 2 A per individual channel.
What is the reference price for the ABB TU810V1 3BSE013230R1?
Observed market reference pricing is approximately $99.00 USD. This figure is an indicative market reference only and not a final quotation.
