PRODUCT INFORMATION
Product Overview
The Allen-Bradley 1771-CP2 is an I/O Chassis Cable within the PLC-5 system family. This gray industrial cable provides an electrical interconnection between an I/O chassis and a remote 1771-P7 power supply. The physical assembly measures 5 feet (1.52 meters) in length. It features conformal coating to protect internal conductors from environmental exposure.
The cable assembly supports a maximum backplane current rating of 1.0 Amps. It operates in ambient temperatures between 32 and 140 degrees Fahrenheit (0 and 60 degrees Celsius). Storage temperature ratings range from -40 to 185 degrees Fahrenheit (-40 to 85 degrees Celsius). Associated system hardware includes the 1771-WN wiring arm.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Cable Length | 5 feet (1.52 m) |
|---|
| Intended Connection | Rack-mounted I/O chassis to remote 1771-P7 power supply |
|---|
| Backplane Current | 1.0 A maximum |
|---|
| Slots Occupied | 1 Slot |
|---|
| Wiring Arm Compatibility | 1771-WN |
|---|
| Module Scan Time | 1.3 to 5 ms |
|---|
| Operating Temperature | 32 to 140 °F (0 to 60 °C) |
|---|
| Storage Temperature | -40 to 185 °F (-40 to 85 °C) |
|---|
| Coating | Conformal coat |
|---|
| Dimensions | 3.5 x 6.5 x 2.0 in (89 x 165 x 51 mm) |
|---|
| Weight | 1.88 lbs (0.85 kg) |
|---|
TECHNICAL INFORMATION
Features
- Cable length measures 5 feet (1.52 meters).
- Connects rack-mounted I/O chassis to remote 1771-P7 power supplies.
- Rated for a maximum backplane current of 1.0 Amps.
- Features conformal coating for protective shielding.
- Operates across ambient temperatures from 0 to 60 degrees Celsius.
TECHNICAL INFORMATION
Applications
- Interconnection between rack-mounted Bulletin 1771 I/O chassis and remote 1771-P7 power supplies.
TECHNICAL INFORMATION
Connections / Interfaces
- Direct interface connection between a rack-mounted 1771 I/O chassis and a Bulletin 1771-P7 power supply.
- Interfaces with 1771-WN wiring arm hardware.
TECHNICAL INFORMATION
Compatibility
- Allen-Bradley Bulletin 1771 rack-mounted I/O chassis.
- Allen-Bradley Bulletin 1771-P7 power supplies.
- Allen-Bradley 1771-WN wiring arms.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSAllen-Bradley Bulletin 1771 rack-mounted I/O chassis. Allen-Bradley Bulletin 1771-P7 power supplies. Allen-Bradley 1771-WN wiring arms.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the 1771-CP2 cable?
The 1771-CP2 cable connects a rack-mounted 1771 I/O chassis to a remote 1771-P7 power supply.
How long is the Allen-Bradley 1771-CP2 cable?
The 1771-CP2 cable measures 5 feet (1.52 meters) in length.
What is the maximum backplane current rating for the 1771-CP2?
The cable is rated for a maximum backplane current of 1.0 Amps.
What temperature ranges are specified for the 1771-CP2?
Operating temperature ranges from 0 to 60 degrees Celsius. Storage temperature ranges from -40 to 85 degrees Celsius.
