PRODUCT INFORMATION
Product Overview
The Allen-Bradley 2711P-K10C15D7 is a PanelView Plus CE 1000 Keypad Panel within the PanelView family. This operator terminal allows direct human interaction with industrial equipment. It provides a 10.4-inch color display for monitoring machinery status. Operator data entry is performed via an integrated keypad. Power is supplied using an input range of 18 to 32 VDC.
This hardware unit is equipped with 256 MB of internal memory. It runs FactoryTalk View Machine Edition runtime software. Supported terminal firmware versions range from 3.13 to 4.48. Communication occurs across ControlNet networks with single or multiple controllers. The unit supports symbolic CIP addressing for ControlLogix platforms and offers redundant cabling capabilities.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Category | Panelviews |
|---|
| Product Line | Panelview Plus 1000 |
|---|
| Weight | 32.00 lbs (14.51 kg) |
|---|
| Display Size | 10.4 in. |
|---|
| Display Color | Color |
|---|
| Input Type | Keypad |
|---|
| Communication | ControlNet |
|---|
| Input Power | 18-32 VDC |
|---|
| Memory | 256 MB |
|---|
| Backlight | 2711P-RL10C |
|---|
| Communication Cable | 1747-KFC15A |
|---|
| Product Lifecycle Status* | Discontinued/Obsolete |
|---|
TECHNICAL INFORMATION
Features
- Equipped with a 10.4-inch color display.
- Utilizes an integrated keypad for operator input.
- Operates from an 18 to 32 VDC power source.
- Includes 256 MB of internal system memory.
- Integrates ControlNet communication supporting scheduled and unscheduled access.
- Supports redundant cabling architectures on ControlNet networks.
- Provides symbolic CIP addressing when interfacing with ControlLogix systems.
- Features a built-in Network Access port for local network connectivity.
TECHNICAL INFORMATION
Applications
- Machinery monitoring and operator data entry in industrial automation systems.
- Deterministic communication with Allen-Bradley ControlLogix processors over ControlNet.
TECHNICAL INFORMATION
Connections / Interfaces
- ControlNet network interface compatible with 1747-KFC15A communication cables.
- Network Access port providing local engineering connection to ControlNet.
- Direct power wiring terminals accepting 18 to 32 VDC input.
TECHNICAL INFORMATION
Installation Guidelines
- Supply direct current strictly within the 18 to 32 VDC range.
- Connect to the network using the designated 1747-KFC15A communication cable.
TECHNICAL INFORMATION
Configuration Guidelines
- Create and configure runtime projects in FactoryTalk View Machine Edition.
- Deploy applications to terminal hardware across firmware revisions 3.13 to 4.48.
- Configure scheduled or unscheduled network traffic within the ControlNet layout.
- Map ControlLogix processor tags using symbolic CIP addressing.
TECHNICAL INFORMATION
Compatibility
- Communicates with single or multiple controllers across ControlNet.
- Interfaces with ControlLogix systems using symbolic CIP addressing.
- Uses 1747-KFC15A communication cables for network connections.
TECHNICAL INFORMATION
Lifecycle / Replacement Information
- The 2711P-K10C15D7 operator terminal is classified as discontinued and obsolete.
- Display backlights are field serviceable using replacement catalog number 2711P-RL10C.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCommunicates with single or multiple controllers across ControlNet. Interfaces with ControlLogix systems using symbolic CIP addressing. Uses 1747-KFC15A communication cables for network connections.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What power input is required for the 2711P-K10C15D7?
The terminal operates on an input voltage supply of 18 to 32 VDC.
Which communication protocol does the 2711P-K10C15D7 use?
The terminal communicates via ControlNet. It supports scheduled access, unscheduled access, and redundant cabling.
What part number is used for replacement backlights?
The internal backlight replacement part number is 2711P-RL10C.
What software is used to develop applications for this panel?
Applications are created using FactoryTalk View Machine Edition for firmware versions 3.13 through 4.48.
What is the market pricing for the 2711P-K10C15D7?
Observed commercial figures are indicative market reference pricing only and are not a final quotation.
