PRODUCT INFORMATION
Product Overview
The Allen-Bradley 2711P-T6M5D is an operator interface in the PanelView series. It features a 5.7-inch monochrome touch display with 320 x 240 resolution. The screen provides 4 grayscale shades for clear graphic presentation. Operators interact with the unit using an integrated resistive touchscreen. This interface handles standard machine monitoring and process control tasks.
The terminal operates on a 24 VDC power input. Internal memory includes 64 MB for application storage and operational execution. Integrated communication ports include RS-232 and USB connections. The terminal supports industrial serial protocols for system communications. Designed for panel mounting, the housing weighs 2.75 lbs (1.25 kg).
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| UPC | 781180130229 |
|---|
| Weight | 2.75 lbs (1.25 kg) |
|---|
| Display Size | 5.7 inches |
|---|
| Terminal Class | HMI Terminal |
|---|
| Display Type | Touch Screen, Monochrome |
|---|
| Color Depth | 4 Grayscale |
|---|
| Mounting Method | Panel Mounted |
|---|
| Resolution | 320 x 240 |
|---|
| Application Use | Monitor and Control |
|---|
| Touch Technology | Resistive |
|---|
| Protocol Support | Serial Protocols |
|---|
| Internal Memory | 64 MB |
|---|
| Power Input | 24 VDC |
|---|
| Communication Ports | RS-232, USB |
|---|
TECHNICAL INFORMATION
Features
- 5.7-inch monochrome display with 320 x 240 resolution.
- 4 grayscale color depth for operational graphics.
- Analog resistive touch screen for direct operator inputs.
- 64 MB internal memory for application data.
- RS-232 and USB communication ports.
- Supports standard industrial serial communication protocols.
- Operates on nominal 24 VDC input power.
TECHNICAL INFORMATION
Applications
- Industrial machine monitoring and status display.
- Direct process control via operator touchscreen inputs.
- Panel-mounted operator interface for serial automation networks.
TECHNICAL INFORMATION
Connections / Interfaces
- One RS-232 serial port for network and controller connectivity.
- USB communication port for peripheral connections.
- DC terminal connections for 24 VDC input power.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the unit directly into an enclosure cutout using panel-mounting hardware.
- Provide clean 24 VDC power according to electrical guidelines.
- Ensure adequate clearance around rear ports for serial and USB cabling.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure serial communication settings to match the host controller network.
- Allocate project data within the 64 MB internal memory limit.
TECHNICAL INFORMATION
Compatibility
- Connects to automation systems supporting RS-232 serial communications.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSConnects to automation systems supporting RS-232 serial communications.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What display technology does the Allen-Bradley 2711P-T6M5D use?
It uses a 5.7-inch monochrome resistive touch screen with 320 x 240 resolution and 4 grayscale levels.
What power input is required for the 2711P-T6M5D?
The unit requires a 24 VDC power input for operation.
What communication ports are available on the 2711P-T6M5D?
The terminal provides RS-232 serial and USB ports for system connectivity.
How much internal memory does the terminal include?
The terminal includes 64 MB of internal memory for monitoring and control applications.
