PRODUCT INFORMATION
Product Overview
The Bently Nevada 3500/65 is a 16-channel Temperature Monitor for the 3500 Series machinery protection system. This monitor accepts inputs from resistance temperature detectors or isolated-tip thermocouple transducers. It conditions multiple temperature points to continuously monitor critical machine thermal parameters.
The module provides an input impedance exceeding 1 MΩ per lead input. Internal current excitation supplies 913 ±7 µA at 25 °C for each RTD channel. The unit operates with a typical power consumption of 3 W across active channels.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Channel Count | 16 |
|---|
| Typical Power Consumption | 3 W |
|---|
| Accepted Input Families | RTD or isolated-tip thermocouple signals |
|---|
| Input Impedance | Greater than 1 MΩ per lead input |
|---|
| RTD Current Source | 913 ±7 µA at 25 °C per transducer |
|---|
| Temperature Resolution | 1 °C or 1 °F |
|---|
| Type E Thermocouple Range | -100 to +1000 °C |
|---|
| Type J Thermocouple Range | 0 to +760 °C |
|---|
| Type K Thermocouple Range | 0 to +1370 °C |
|---|
| Type T Thermocouple Range | -160 to +400 °C |
|---|
TECHNICAL INFORMATION
Features
- Monitors up to 16 temperature channels simultaneously within a 3500 rack.
- Accepts isolated-tip thermocouples and resistance temperature detector inputs.
- Supplies 913 ±7 µA transducer excitation current for connected RTDs.
- Delivers temperature measurement resolution of 1 °C or 1 °F.
TECHNICAL INFORMATION
Connections / Interfaces
- Provides 16 individual input channels for temperature sensor lead connections.
- Features input impedance greater than 1 MΩ per lead connection.
TECHNICAL INFORMATION
Compatibility
- Compatible with the Bently Nevada 3500 machinery protection rack system.
- Supports Type E, Type J, Type K, and Type T thermocouples.
- Supports standard resistance temperature detector sensor inputs.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with the Bently Nevada 3500 machinery protection rack system. Supports Type E, Type J, Type K, and Type T thermocouples. Supports standard resistance temperature detector sensor inputs.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
How many input channels does the Bently Nevada 3500/65 support?
The 3500/65 monitor supports up to 16 independent temperature input channels.
What sensor types can connect to the 3500/65 monitor?
It accepts RTD sensors and isolated-tip Type E, J, K, and T thermocouples.
What is the typical power consumption of the 3500/65 module?
Typical power consumption for the 3500/65 module is 3 W.
What is the reference price for the Bently Nevada 3500/65?
Pricing depends on condition and availability. Stated figures are indicative market reference pricing only and are not a final quotation.
