PRODUCT INFORMATION
Product Overview
The General Electric 269PLUS-DO-315-100P-HI Multilin Motor Management Relay provides comprehensive motor protection. This drawout unit features pre-set hardware options defined by its catalog configuration. It incorporates a :1 phase current transformer and a 2000:1 ground current transformer. The relay operates across a high voltage control range of 90 to 300 VDC or 80 to 265 VAC.
Internal output circuitry provides fail-safe operation for trip and auxiliary 2 circuits. Alarm and auxiliary 1 circuits operate without fail-safe circuitry. Relay contact arrangement option 5 configures alarm contacts as normally open. Auxiliary 1 and auxiliary 2 contacts are normally closed. The unit monitors temperature using 100 Ohm platinum RTD inputs. Users can define custom overload curves alongside standard protection profiles.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer Location | Markham, Ontario, Canada |
|---|
| Software | EnerVista 269 |
|---|
| User Manual | 1601-0013-E4 |
|---|
| Running Hours Counter Accuracy | ±1% |
|---|
| Control Power Frequency | 50/60 Hz |
|---|
| Max. Power Consumption | 20 VA |
|---|
TECHNICAL INFORMATION
Features
- Drawout chassis configuration with factory-set hardware options.
- Support for 100 Ohm platinum resistance temperature detectors.
- High voltage control power rating of 90 to 300 VDC and 80 to 265 VAC.
- Phase CT ratio of :1 and ground CT ratio of 2000:1.
- Option 5 contact setup with normally open alarm and normally closed auxiliaries.
- Field-programmable parameters and custom motor overload curve capability.
TECHNICAL INFORMATION
Applications
- Three-phase industrial motor management and thermal monitoring.
- Mechanical equipment protection in power and process automation systems.
TECHNICAL INFORMATION
Connections / Interfaces
- Terminals for :1 phase CT and 2000:1 ground CT connections.
- Input channels configured for 100 Ohm platinum RTD sensors.
- High voltage control power terminals operating at 50/60 Hz.
TECHNICAL INFORMATION
Installation Guidelines
- Install one dedicated relay per monitored motor circuit.
- Ensure control supply voltage matches the specified high voltage rating.
- Mount the drawout assembly securely within the control enclosure.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure operating parameters using compatible EnerVista 269 software.
- Select standard overload curves or input custom breakpoints.
- Consult instruction manual 1601-0013-E4 for complete parameter registers.
TECHNICAL INFORMATION
Compatibility
- Compatible with 100 Ohm platinum RTD temperature sensors.
- Supports EnerVista 269 software for setup and monitoring.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with 100 Ohm platinum RTD temperature sensors. Supports EnerVista 269 software for setup and monitoring.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What control voltage range does the 269PLUS-DO-315-100P-HI support?
The high voltage power supply operates on 90 to 300 VDC or 80 to 265 VAC at 50/60 Hz.
Which RTD sensor type is compatible with this relay?
This unit is factory-configured specifically for 100 Ohm platinum RTD temperature inputs.
What does option 5 mean for output relay contact states?
Option 5 designates normally open contacts for alarm and normally closed contacts for auxiliary 1 and 2.
