PRODUCT INFORMATION
Product Overview
The General Electric DS200RTBAG2A is a Mark V relay terminal board designed for turbine control and drive cabinets. It provides ten additional relay channels to the host system. The assembly integrates with General Electric exciter cabinets and driver systems. Both remote terminal control and local area network I/O control are supported. The board belongs to the Mark V Series grouping Group 2 designation.
Ten relays populate the board across two distinct functional groupings. Seven positions feature DPDT relays with two Form C contacts rated at 10A each. Three positions utilize 4PDT relays containing four contacts rated at 1A each. Every relay incorporates a 110 VDC coil. Onboard relays feature protection from 130 VAC metal oxide varistors. Replaceable relays permit field servicing and standard maintenance workflows.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Instruction Manual | GEI-100167 |
|---|
| Mark V Series Grouping | Group 2 |
|---|
TECHNICAL INFORMATION
Features
- Provides ten onboard relay spots for host system control.
- Includes seven DPDT relays with Form C contacts rated at 10A.
- Features three 4PDT relays with contacts rated at 1A.
- Equipped with 110 VDC relay coils protected by 130 VAC varistors.
- Supports both remote and LAN I/O terminal control connections.
- Configurable manually using onboard hardware jumpers such as JP8 and JP9.
- Protected with a standard protective printed circuit board surface coating.
TECHNICAL INFORMATION
Applications
- General Electric Speedtronic Mark V turbine control and management systems.
- Wind, gas, and steam turbine automated drive assemblies.
- General Electric brand exciter and driver cabinet installations.
TECHNICAL INFORMATION
Connections / Interfaces
- Terminal connections support remote and local area network I/O control.
- Locations K20 through K26 house the seven DPDT relay sockets.
- Three additional sockets house the 4PDT relay components.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the board inside compatible GE exciter or drive cabinets.
- Consult instruction manual GEI-100167 for specific cabinet wiring guidelines.
- Ensure system power is de-energized before handling jumper or relay components.
TECHNICAL INFORMATION
Configuration Guidelines
- Manually movable hardware jumpers configure operational modes.
- Jumper JP8 selects the K20 through K22 power source.
- Jumper JP9 establishes the RPL 1 connection circuit.
- Factory-printed silk screen labels identify each jumper using standard J designations.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric Mark V turbine control systems.
- Designed for installation within GE exciter cabinets and drive units.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with General Electric Mark V turbine control systems. Designed for installation within GE exciter cabinets and drive units.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the DS200RTBAG2A board?
It provides ten relay channels for remote and LAN I/O control in Mark V turbine systems.
What relay configurations are installed on the DS200RTBAG2A?
The board contains seven DPDT 10A relays and three 4PDT 1A relays with 110 VDC coils.
Which instruction manual covers installation and wiring for DS200RTBAG2A?
Manual GEI-100167 outlines detailed wiring, installation, and jumper selection instructions.
