PRODUCT INFORMATION
Product Overview
The General Electric IC200CHS101A IC200CHS101 is a VersaMax disconnect-style interposing I/O terminal. This unit provides 16 field I/O points across 36 box-style wiring terminals. It establishes field signal connections while providing mechanical isolation for maintenance operations. The assembly supports both solid and stranded copper conductor connections.
The terminal features dedicated J1 and J2 multi-pin interconnects. The J1 connector interfaces directly with the VersaMax I/O carrier. The J2 expansion interface connects directly to an adjacent expansion base. Each terminal accepts dual conductors within a wire gauge range of #12 to #24 AWG.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Number of I/O Points | 16 points |
|---|
| Total Terminals | 36 box-style terminals |
|---|
| Wire Size (AWG) | #12 to #24 AWG |
|---|
| Solid Copper Wire Size | 0.2 to 4.0 mm² |
|---|
| Stranded Copper Wire Size | 0.2 to 2.5 mm² |
|---|
| Dual-wire Capability | Two wires allowed per terminal |
|---|
| Terminal Torque | 0.5 to 0.6 Nm |
|---|
| Connector Interface | J1 connector to I/O carrier |
|---|
| Expansion Interface | J2 connector for expansion base |
|---|
| Signal Isolation | Mechanical isolation |
|---|
| Pollution Degree | Pollution degree 2 |
|---|
| Vertical Spacing Clearance | 2 inches |
|---|
| Horizontal Spacing Clearance | 1 inch |
|---|
| Net Weight | 1.36 kg (3.00 lbs) |
|---|
TECHNICAL INFORMATION
Features
- Provides 16 field I/O connection points.
- Equipped with 36 box-style screw terminals.
- Allows two wires per terminal clamp.
- Includes J1 connector for carrier attachment.
- Provides J2 connector for base expansion.
- Features mechanical signal isolation design.
TECHNICAL INFORMATION
Connections / Interfaces
- J1 connector routes signals directly to the VersaMax carrier.
- J2 interface enables connection to an expansion base.
- Accommodates solid copper conductors from 0.2 to 4.0 mm².
- Accommodates stranded copper wire from 0.2 to 2.5 mm².
- Accepts wire sizes ranging from #12 to #24 AWG.
TECHNICAL INFORMATION
Installation Guidelines
- Maintain 2 inches of vertical clearance around the module.
- Maintain 1 inch of horizontal clearance for proper ventilation.
- Tighten box terminal screws to a torque between 0.5 and 0.6 Nm.
- Install in environments conforming to Pollution Degree 2 standards.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the function of the General Electric IC200CHS101A IC200CHS101 terminal?
It provides 16 field wiring points and mechanical disconnect isolation for VersaMax I/O carrier modules.
What wire sizes are supported by the IC200CHS101 terminals?
The terminals accept #12 to #24 AWG copper conductors, supporting solid or stranded wire.
What is the reference price for the IC200CHS101?
Observed market reference pricing is approximately $219.00 USD for refurbished units. This figure is an indicative market reference only and is not a final quotation.
Can multiple wires be connected to a single IC200CHS101 terminal point?
Yes, each box terminal supports dual-wire capability for up to two conductors.
