Product Overview
The General Electric IC200CPU001 is a VersaMax processor module for DIN rail or panel mounting. It processes up to 2048 discrete inputs and 2048 discrete outputs during automated operations. The unit provides 34 Kbytes of configurable memory for user logic, registers, and analog I/O words. Memory architecture uses system flash storage alongside battery-backed random-access memory. Boolean execution speed averages 1.8 milliseconds per 1K of logic instructions. The hardware features a physical run and stop mode switch behind the protective front door.
Communication interfaces include one built-in RS-232 port and one built-in RS-485 serial port. Supported communication protocols include Modbus RTU Slave, SNP Slave, and Serial I/O. Internal data allocation includes 1024 discrete internal bits and 256 discrete temporary bits. The controller also provides 1280 global discrete bits and 32 Modbus registers. An integrated battery-backed real-time clock maintains an accuracy of 100 ppm across operating temperatures. Backplane current consumption measures 140 mA at 5 Volts and 100 mA at 3.3 Volts.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Backplane Current Consumption | 140 mA for 5 Volts, 100 mA for 3.3 Volts |
|---|
| Battery Backed RTC | Installed |
|---|
| Boolean Execution Speed | 1.8 ms / K |
|---|
| Communication Ports | One (1) RS232; One (1) RS485 |
|---|
| Configurable Memory | 34K Bytes for Program, Registers, I/O Analog Words |
|---|
| Discrete Input | 2048 |
|---|
| Discrete Inputs | 2048 points |
|---|
| Discrete Internal Bits | 1024 points |
|---|
| Discrete Outputs | 2048 points |
|---|
| Discrete Temporary Bits | 256 points |
|---|
| Discrete output | 2048 |
|---|
| Floating Point data | Supported |
|---|
| Floating point math | Supported |
|---|
| Global Discrete Bits | 1280 points |
|---|
| Internal memory | 384Kbytes configurable memory |
|---|
| Memory | 34 KB |
|---|
| Memory type | System flash, battery-backed RAM |
|---|
| Modbus Registers | 32 |
|---|
| Override functions | Supported |
|---|
| Product Description | Central Processing Unit (CPU) |
|---|
| Product Line | Versamax |
|---|
| RTC Accuracy | 100ppm (0.01%) or +/- 9sec/day |
|---|
| Real-Time Clock Accuracy | 100 ppm |
|---|
| Serial Ports | 2 |
|---|
| Supported programming language | Ladder Diagram, Instruction list |
|---|
| Supported protocols | SNP Slave, RTU Slave, Serial I/O |
|---|
| Supported serial protocols | Modbus RTU Slave, SNP, Serial I/O |
|---|
| Temporary bits | 256 points |
|---|
| Type of Memory Storage | RAM and Flash |
|---|
| Typical Scan Rate | 1.8 milliseconds per 1K of logic (boolean contacts) |
|---|
| User Memory | 34K Bytes |
|---|
| Weight | 0.63 lbs (0.28 kg) |
|---|
TECHNICAL INFORMATION
Features
- Processes up to 2048 discrete inputs and 2048 discrete outputs.
- Allocates 34 Kbytes of configurable user memory for logic and registers.
- Executes Boolean contacts at a typical rate of 1.8 ms per 1K.
- Integrates one RS-232 serial port and one RS-485 serial interface.
- Supports Modbus RTU Slave, SNP Slave, and Serial I/O protocols.
- Contains 1024 internal bits, 256 temporary bits, and 1280 global bits.
- Features a battery-backed real-time clock accurate to 100 ppm.
- Includes front status LED indicators and an execution mode switch.
TECHNICAL INFORMATION
Applications
- Industrial machinery control using discrete I/O automation sequences.
- Distributed monitoring using Modbus RTU Slave communications.
- Supervisory data exchange with operator interfaces via SNP Slave protocol.
TECHNICAL INFORMATION
Connections / Interfaces
- One integrated RS-232 serial communication port.
- One integrated RS-485 serial communication port.
- Backplane interface providing 5 VDC and 3.3 VDC electrical connections.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the module directly onto a DIN rail or an enclosure panel.
- Install the unit alongside a compatible VersaMax power supply.
- Maintain clear space around the housing for proper ventilation inside the enclosure.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure logic using CIMPLICITY Machine Edition Logic Developer, VersaPro, or Control Programmer.
- Set serial communication ports to Modbus RTU Slave or SNP Slave operation.
- Control program execution using the run/stop mode switch behind the front door.
TECHNICAL INFORMATION
Compatibility
- Operates with compatible VersaMax power supplies providing backplane power.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSOperates with compatible VersaMax power supplies providing backplane power.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the user memory capacity of the IC200CPU001?
The processor provides 34 Kbytes of configurable user memory for logic, registers, and analog words.
Which serial protocols does the IC200CPU001 support?
The module supports Modbus RTU Slave, SNP Slave, and Serial I/O communication protocols.
What mounting options are supported for this processor?
The processor can be installed directly onto a DIN rail or panel mounted.
