PRODUCT INFORMATION
Product Overview
The General Electric IC670CHS004 is a Field Control terminal block designed for industrial signal monitoring systems. It supports millivolt-level thermocouple signals for precise process temperature monitoring. The unit features 20 direct screw-clamp terminals that support two modules per assembly block. Each connection securely terminates field wiring sized from 16 AWG to 20 AWG. This terminal block handles a maximum current rating of up to 10 Amperes.
Passive electrical isolation protects signal pathways from unexpected line interference. The assembly supports standard DIN rail mounting inside control cabinets and field enclosures. It operates within a standard temperature span of 0°C to 60°C. Storage temperature ratings span from -40°C to 85°C. In addition, the hardware complies with pollution degree 2 industrial installation standards.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 0.50 lbs (0.23 kg) |
|---|
| UPC | 799705805682 |
|---|
| Number of Terminals | 20 terminals |
|---|
| Terminal Connection Wiring | AWB 16-20 |
|---|
| Terminal Torque | 4.5 pounds on an inch |
|---|
| Maximum Current on Terminals | 10 Amperes |
|---|
| Number of Modules per Block | 2 modules |
|---|
| Input Signal Type | Millivolt-level thermocouple signals |
|---|
| Signal Wiring | Direct screw-terminal connection |
|---|
| Electrical Isolation | Passive |
|---|
| Module Mounting | DIN rail mounted |
|---|
| Operating Temperature Range | 0°C to 60°C |
|---|
| Storage Temperature Range | -40°C to 85°C |
|---|
| Pollution Degree | Pollution degree 2 |
|---|
TECHNICAL INFORMATION
Features
- Configured with 20 direct screw clamp terminals for signal connections.
- Accommodates up to two modules per block.
- Engineered specifically for millivolt-level thermocouple signals.
- Rated for maximum continuous current up to 10 Amperes.
- Provides passive electrical isolation between circuits.
- Designed for standard DIN rail installation in industrial enclosures.
TECHNICAL INFORMATION
Applications
- Temperature monitoring in industrial Field Control automation architectures.
- Millivolt thermocouple sensor signal termination.
TECHNICAL INFORMATION
Connections / Interfaces
- Twenty direct screw-clamp terminals for field wiring.
- Terminal accommodation for 16 AWG to 20 AWG wire conductors.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the unit directly onto a standard DIN rail inside an enclosure.
- Strip wiring cleanly and use wire sizes between 16 and 20 AWG.
- Tighten terminal screws to a specified torque of 4.5 inch-pounds.
- Maintain ambient operating temperatures between 0°C and 60°C.
TECHNICAL INFORMATION
Compatibility
- Compatible with GE Field Control thermocouple module configurations.
TECHNICAL INFORMATION
Compliance and Certifications
- Pollution degree 2 rated for industrial operating environments.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with GE Field Control thermocouple module configurations.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What signal types does the General Electric IC670CHS004 process?
The IC670CHS004 processes millivolt-level thermocouple input signals from field sensors.
How many field wiring terminals are present on the IC670CHS004?
The block provides 20 direct screw clamp terminals for field connection wiring.
What is the recommended tightening torque for IC670CHS004 terminal screws?
Fasten the terminal connection screws to a torque specification of 4.5 inch-pounds.
