PRODUCT INFORMATION
Product Overview
The General Electric IC694PWR331 is a PACSystems RX3i expansion and remote base power supply module. It operates from a nominal input rating of 24 VDC. The unit delivers a total output capacity of 30 watts across its supported buses. It supports installation in expansion backplanes and remote base chassis. This module maintains stable electrical delivery across multi-rack RX3i architectures.
The module provides up to 30 watts at 5 VDC output. For 24 VDC circuits, it supplies up to 20 watts for isolated loads. It provides up to 15 watts for relay circuits. The 24 VDC output current capacity reaches 0.8 amperes. The unit also accommodates high-speed serial bases to maintain efficient communication across industrial racks.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 1.94 lbs (0.88 kg) |
|---|
| Module Type | Expansion Power Supply, Remote Base Power Supply |
|---|
| Nominal Rated Voltage | 24 Volts DC |
|---|
| Backplane Option | Remote Bases |
|---|
| High-Capacity Power Supply | Yes |
|---|
| High-Speed Serial Bases | Supported |
|---|
| Total Output Source Rating | 30 Watts |
|---|
| Output Source Rating at 5V | 30 Watts |
|---|
| Output Source Rating at 24V Relay | 15 Watts |
|---|
| Output Source Rating at 24V Isolated | 20 Watts |
|---|
| Output Current Capacity at 24V DC | 0.8 Amps |
|---|
TECHNICAL INFORMATION
Features
- Operates with a nominal input voltage of 24 VDC.
- Delivers a total maximum power rating of 30 watts.
- Supplies up to 30 watts on the 5 VDC output rail.
- Provides 20 watts for isolated 24 VDC output circuits.
- Provides 15 watts for 24 VDC relay power requirements.
- Delivers an output current capacity of 0.8 amperes at 24 VDC.
- Compatible with remote bases and expansion chassis architectures.
- Accommodates high-speed serial base communications.
TECHNICAL INFORMATION
Applications
- Supplying power to PACSystems RX3i expansion backplanes.
- Distributing operational power in remote base configurations.
- Powering mixed 5 VDC logic and 24 VDC field relay loads.
TECHNICAL INFORMATION
Connections / Interfaces
- Connects directly into standard PACSystems RX3i remote and expansion base slots.
- Interfaces with high-speed serial backplane communication lines.
- Provides terminal connections for nominal 24 VDC input power.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the module into designated power supply slots on remote or expansion bases.
- Ensure input supply lines deliver clean nominal 24 VDC power.
- Verify total backplane consumption does not exceed the 30 watt limit.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric PACSystems RX3i remote bases.
- Compatible with PACSystems RX3i expansion bases.
- Supports PACSystems RX3i high-speed serial base configurations.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with General Electric PACSystems RX3i remote bases. Compatible with PACSystems RX3i expansion bases. Supports PACSystems RX3i high-speed serial base configurations.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the General Electric IC694PWR331?
It serves as an expansion and remote base power supply within PACSystems RX3i control systems.
What input voltage does the IC694PWR331 require?
The IC694PWR331 requires a nominal input voltage of 24 VDC for operation.
What are the output power ratings of the IC694PWR331?
The module provides 30 watts total output. It delivers 30 watts at 5 VDC. It also supplies 20 watts isolated and 15 watts relay power at 24 VDC.
What is the reference price for the IC694PWR331?
Pricing varies based on supply, condition, and availability. Stated figures are indicative market reference pricing only and are not a final quotation.
