Product Overview
The General Electric IC697BEM711 is a Series 90-70 Bus Receiver Module designed for PLC rack expansion. This module operates within an IC697 PLC system to connect downstream expansion racks. It allows engineers to install additional input, output, and specialty modules across the automation architecture. The unit supports expansion configurations reaching up to seven expansion racks. Data communication across the parallel expansion interface operates at 500 kilobytes per second.
The IC697BEM711 features two front 25-pin D-shell data connectors for daisy-chain cable connections. Port 1 connects towards the CPU rack or preceding bus interface module. Port 2 extends the communication line away from the CPU toward additional racks. System fault isolation separates rack communication, simplifying targeted troubleshooting during service operations. An output hold function permits modules in a disconnected rack to retain their last operating state. The module occupies a single slot and draws 800 mA at 5 Volts DC backplane power.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 1.75 lbs (0.79 kg) |
|---|
| Product Description | Bus Expansion Module (BEM) |
|---|
| Slot width | Single slot |
|---|
| Mounting location | Series 90-70 CPU baseplate |
|---|
| Compatibility | IC697 PLC |
|---|
| Status LED indicators | Module OK; Last Rack; Bus Active |
|---|
| Status LEDs | OK, BUS Active, Last Rack |
|---|
| No. of Ports | Two (2) 25-pin D-shell connectors |
|---|
| Slot required | 1 |
|---|
| Module location | Slot 1 |
|---|
| Port 1 function | Expansion port towards the CPU |
|---|
| Voltage input | 5 Volts DC |
|---|
| Rack Addressing | via Jumper settings |
|---|
| Port 2 function | Expansion port away from the CPU |
|---|
| Current input | 0.8 Amps |
|---|
| Data connectors | 2 |
|---|
| Electrical Isolation | Non-isolated differential communication |
|---|
| No. of expansion racks | Seven (7) |
|---|
| Effective Data Rate | 500 Kbytes/sec |
|---|
| Maximum cable length | 50 feet (15meters) |
|---|
| terminator Plug | IC697ACC702 |
|---|
| Data Rate | 500 Kbytes/sec |
|---|
| Backplane current draw | 800 mA at 5VDC |
|---|
TECHNICAL INFORMATION
Features
- Provides high-speed parallel bus expansion supporting up to seven expansion racks.
- Features two 25-pin D-shell data communication ports for daisy-chain wiring.
- Delivers an effective data transmission rate of 500 kilobytes per second.
- Includes system fault isolation to safeguard communication integrity during maintenance.
- Supports output hold functionality to preserve machine states upon rack interruption.
- Provides three front-panel status LEDs for Module OK, Last Rack, and Bus Active.
- Occupies a single chassis slot in slot 1 of the CPU baseplate.
TECHNICAL INFORMATION
Applications
- Expansion of General Electric Series 90-70 PLC systems requiring additional I/O capacity.
- Distributed rack architectures requiring physical rack separation up to 15 meters.
- Industrial automation systems requiring controlled output hold during chassis maintenance.
TECHNICAL INFORMATION
Connections / Interfaces
- Port 1 connects upstream toward the CPU or previous bus interface module.
- Port 2 connects downstream away from the CPU toward additional expansion racks.
- Both interfaces use 25-pin D-shell connectors for differential parallel communication.
- The final expansion rack requires an IC697ACC702 terminator plug.
TECHNICAL INFORMATION
Installation Guidelines
- Always turn off system power before installing the module into the designated slot.
- Install the unit into slot 1 of the Series 90-70 CPU baseplate.
- Configure rack addressing using the on-board jumper settings.
- Ensure total interconnecting cable length does not exceed 50 feet or 15 meters.
- Install the IC697ACC702 terminating plug on the final rack in the expansion chain.
TECHNICAL INFORMATION
Configuration Guidelines
- Configure the module using MS-DOS or Windows-based programming software packages.
- Verify rack address jumper settings match software hardware configuration tables.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric Series 90-70 IC697 PLC systems.
- Supports interconnect cables IC600WD005A, IC600WD010A, IC600WD025A, and IC600WD050A.
- Requires IC697ACC702 terminator plug on the final expansion rack.
- Complies with VME standard C.1 specifications.
