Product Overview
The General Electric IC697BEM742 is a bus controller module for the Series 90-70 platform. This unit manages industrial communication across dual redundant bus channels. The module provides 2 Megabytes of internal RAM alongside 2 Megabytes of non-volatile flash memory. It supports deterministic data transfer at speeds reaching 1 Mbit per second.
The IC697BEM742 requires a single chassis slot for system integration. Integrated front-panel LED indicators display operational status for direct visual diagnostics during operation. The module functions across an operating temperature range of 0°C to 60°C. It tolerates non-operating storage conditions from -40°C up to 85°C. Standard rack installation supports site altitudes up to 1000 meters.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 1.25 lbs (0.57 kg) |
|---|
| RAM Memory | 2 Megabytes |
|---|
| Flash Memory | 2 Megabytes |
|---|
| Data Transmission Rate | 1 Mbit/second |
|---|
| Bus Channels | Dual channels for redundant bus capability |
|---|
| Slot Requirement | Single Slot |
|---|
| LED Indicators | Front-panel LEDs |
|---|
| Min. Operating Temperature | 0°C |
|---|
| Max. Operating Temperature | 60°C |
|---|
| Min. Storage Temperature | -40°C |
|---|
| Max. Storage Temperature | 85°C |
|---|
| Installation Altitude | 1000 m |
|---|
TECHNICAL INFORMATION
Features
- Dual bus channels provide physical architecture for redundant bus operations.
- Communication transmission rate operates at 1 Mbit per second.
- Memory architecture includes 2 Megabytes of RAM and 2 Megabytes of flash storage.
- Compact single-slot footprint conserves backplane capacity within the Series 90-70 rack.
- Front-panel LED indicators provide status monitoring and diagnostic fault verification.
TECHNICAL INFORMATION
Connections / Interfaces
- The unit interfaces directly with the backplane using a single rack slot.
- Dual communication channels establish redundant network paths across connected industrial devices.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the controller securely into a single slot within the Series 90-70 rack frame.
- Maintain operating ambient temperatures between 0°C and 60°C inside the cabinet.
- Confirm site elevation does not exceed the maximum rating of 1000 meters.
