PRODUCT INFORMATION
Product Overview
The General Electric IC697CPM914 is a central processing unit module for the Series 90-70 control system. It incorporates an Intel 80486DX microprocessor running at a 32 MHz clock speed. The processor uses 32-bit instructions to execute application logic. It includes 512 KB of user logic RAM maintained by battery backup to protect data during power interruptions.
This module manages up to 12,000 discrete inputs and outputs along with 8,000 analog input/output channels. A front-panel 15-pin D-type connector provides a dedicated serial port for communications. Front-facing LED indicators display operational and diagnostic status in real time. The unit draws 2.8 A of operating current and tolerates non-condensing relative humidity from 5% to 95%.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 2.75 lbs (1.25 kg) |
|---|
| Microprocessor | Intel 80486DX |
|---|
| Clock Speed | 32 MHz |
|---|
| Instruction Size | 32 bit |
|---|
| User Logic RAM | 512 KB |
|---|
| Memory Type | Battery-backed RAM |
|---|
| Discrete I/O Points | 12,000 discrete inputs/outputs |
|---|
| Analog I/O Channels | 8,000 analog I/O |
|---|
| Serial Ports | One 15-pin D-type connector |
|---|
| Current Draw | 2.8 A |
|---|
| Status Indicators | LEDs |
|---|
| Relative Humidity | 5 to 95% (non-condensing) |
|---|
TECHNICAL INFORMATION
Features
- Equipped with an Intel 80486DX 32 MHz processor utilizing 32-bit instructions.
- Provides 512 KB of battery-backed RAM for user logic execution.
- Supports up to 12,000 discrete I/O points and 8,000 analog channels.
- Includes one 15-pin D-type serial communication port.
- Features integrated LED indicators for real-time status diagnostics.
- Operates in relative humidity ranges between 5% and 95% non-condensing.
TECHNICAL INFORMATION
Connections / Interfaces
- The module provides a single 15-pin D-type connector for serial port communications.
- Front-panel LEDs provide diagnostic feedback on module operating conditions.
TECHNICAL INFORMATION
Installation Guidelines
- Verify that the chassis power supply can accommodate the 2.8 A operational current draw.
- Ensure ambient installation conditions maintain non-condensing relative humidity between 5% and 95%.
- Check the memory backup battery during module setup to secure stored logic RAM.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What processor architecture does the GE IC697CPM914 use?
It uses an Intel 80486DX 32-bit microprocessor operating at a clock speed of 32 MHz.
How much user memory is available on the IC697CPM914 module?
The IC697CPM914 includes 512 KB of user logic RAM supported by battery backup.
What is the maximum I/O capacity of the IC697CPM914?
It addresses up to 12,000 discrete input and output points alongside 8,000 analog channels.
What is the operational current requirement for the IC697CPM914?
The IC697CPM914 draws 2.8 A during standard operational service.
