PRODUCT INFORMATION
Product Overview
The General Electric IC697VAL132 is an analog Input Module for the Series 90-70 family. It also supports RX7i PACSystems architectures. The unit functions as an analog-to-digital converter dedicated to current signals. It provides 16 differential channels or 31 single-ended channels. Each channel processes current inputs with a 12-bit resolution.
The hardware accommodates several standard current measurement ranges. These ranges include 0 to 20 mA, 4 to 20 mA, and 5 to 25 mA. Isolation is rated at 1500V RMS between any input terminal and the backplane. Minimum impedance is 10 Mohm for line-to-common and line-to-line connections. The module requires a maximum current draw of 2.5A from the 5V bus.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 3.00 lbs (1.36 kg) |
|---|
| Module Type | Input Module |
|---|
| Input Type | Analog-to-Digital Converter, Current |
|---|
| Number of Differential Channels | 16 |
|---|
| Number of Single-Ended Channels | 31 |
|---|
| Current Resolution | 12 Bits |
|---|
| Analog Input Current | 0 mA to 20 mA, 4 mA to 20 mA, or 5 mA to 25 mA |
|---|
| Isolation | 1500V RMS (any input to the backplane) |
|---|
| Minimum Impedance | 10 Mohm (line-to-common and line-to-line) |
|---|
| Maximum Required Current from 5V Bus | 2.5A |
|---|
TECHNICAL INFORMATION
Features
- Analog-to-digital conversion with 12-bit current resolution.
- Selectable channel architecture supporting 16 differential or 31 single-ended inputs.
- Accepts input current spans of 0 to 20 mA, 4 to 20 mA, and 5 to 25 mA.
- Galvanic isolation rated at 1500V RMS between any input and the backplane.
- Input impedance rating of 10 Mohm minimum across line-to-line and line-to-common paths.
- Maximum current requirement of 2.5A from the 5V backplane bus.
TECHNICAL INFORMATION
Applications
- Current loop sensor monitoring in industrial PLC racks.
- Analog current signal digitization from field transmitters.
- Instrumentation acquisition requiring differential or single-ended channel wiring.
TECHNICAL INFORMATION
Connections / Interfaces
- Chassis backplane interface drawing up to 2.5A from the 5V bus.
- Field connections configurable for 16 differential or 31 single-ended current circuits.
TECHNICAL INFORMATION
Installation Guidelines
- Verify that the rack power supply can provide 2.5A on the 5V bus.
- Confirm input signal loops match the configured 0-20 mA, 4-20 mA, or 5-25 mA ranges.
TECHNICAL INFORMATION
Configuration Guidelines
- Select either 16 differential or 31 single-ended mode during hardware configuration.
- Configure scaling parameters to correspond with 12-bit analog-to-digital resolution.
TECHNICAL INFORMATION
Compatibility
- General Electric Series 90-70 backplane systems.
- General Electric RX7i PACSystems architectures.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSGeneral Electric Series 90-70 backplane systems. General Electric RX7i PACSystems architectures.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What channel configurations are available on the IC697VAL132?
The module supports either 16 differential channels or 31 single-ended current channels.
What input current ranges does the module accept?
It accepts 0 to 20 mA, 4 to 20 mA, and 5 to 25 mA input spans.
What is the backplane isolation rating for the IC697VAL132?
The module provides 1500V RMS isolation between any input and the backplane.
What is the maximum current draw from the 5V bus?
The module requires a maximum current draw of 2.5A from the 5V bus.
