PRODUCT INFORMATION
Product Overview
The General Electric IC698CPE040 is a PACSystems RX7i Processor Module designed for industrial programmable logic controller architectures. This processor module runs at a clock speed of 1800 MHz to execute control logic. It features 64 MB of integrated system memory to support runtime application programs. Power is drawn directly from the system backplane using multiple voltage inputs. The module requires 5 VDC, +24 VDC, and -24 VDC supplies from the rack.
The processor mounts vertically into an RX7i chassis inside industrial control cabinets. It operates in environments with ambient temperatures between 0 and 60 degrees Celsius. Integrated Ethernet interfaces provide network communication with other automation devices. The module also features diagnostic LEDs on the front panel for status monitoring. It has an operational altitude rating of up to 1000 meters above sea level.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 3.75 lbs (1.70 kg) |
|---|
| Max. Operating Altitude | 1000 meters above sea level |
|---|
| PLC | RX7i |
|---|
| Power Supply | 5 VDC, +24 VDC, -24 VDC |
|---|
| Interface | Ethernet |
|---|
| Clock Speed | 1800 MHz |
|---|
| Memory | 64 MB |
|---|
| Mounting | Chassis |
|---|
| Power Source | Backplane |
|---|
| Mounting Orientation | Vertical |
|---|
| Operating Temperature | 0 to 60 ⁰C |
|---|
| Diagnostic LEDs | Yes |
|---|
TECHNICAL INFORMATION
Features
- Operates at an internal clock speed of 1800 MHz.
- Contains 64 MB of built-in system memory.
- Integrates onboard Ethernet interfaces for industrial networking.
- Front-panel diagnostic LEDs indicate operating and fault status.
- Draws backplane operating power via 5 VDC, +24 VDC, and -24 VDC rails.
TECHNICAL INFORMATION
Applications
- General Electric PACSystems RX7i programmable controller assemblies.
- Industrial plant automation requiring high-speed Ethernet communication.
TECHNICAL INFORMATION
Connections / Interfaces
- Ethernet interface ports for communication with network components.
- Backplane connector for power delivery and chassis bus communication.
TECHNICAL INFORMATION
Installation Guidelines
- Install the unit in a vertical orientation within the RX7i chassis.
- Ensure control cabinets maintain ambient operating temperatures between 0 and 60 °C.
- Verify that system elevation does not exceed 1000 meters above sea level.
TECHNICAL INFORMATION
Compatibility
- Compatible with General Electric PACSystems RX7i chassis and backplane systems.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSCompatible with General Electric PACSystems RX7i chassis and backplane systems.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the clock speed and memory capacity of the IC698CPE040?
The IC698CPE040 operates at 1800 MHz and contains 64 MB of integrated system memory.
How does the IC698CPE040 processor module receive power?
The module draws power from the RX7i backplane, requiring 5 VDC, +24 VDC, and -24 VDC.
What is the required mounting orientation for this module?
The processor module is built for vertical mounting directly into an RX7i chassis.
What network interface is integrated into the IC698CPE040?
The IC698CPE040 includes built-in Ethernet interfaces for industrial control network communications.
