PRODUCT INFORMATION
Product Overview
The Allen-Bradley 1761-CBL-HM02 MicroLogix HHP Cable connects a MicroLogix 1000 controller to a hand-held programmer. This specialized assembly provides dedicated RS-232 serial communication for configuration and monitoring. The cable spans a total length of 2 meters. Both cable ends terminate in right-angle 8-pin Mini-DIN male connectors with secure locking tabs.
The assembly functions across an operating temperature range between 0 °C and 60 °C. Storage temperature tolerance spans from -40 °C to 85 °C. Relative humidity tolerance ranges from 5% to 95% non-condensing for industrial factory floor settings. The total shipping weight for the assembly is 0.56 lbs.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Product Line | MicroLogix 1000 |
|---|
| Weight | 0.56 lbs (0.26 kg) |
|---|
| UPC | 662468489690 |
|---|
| Connector A (for PLC End) | 8-Pin Mini-DIN (male, right-angle connector with lock mechanism) |
|---|
| Connector B (for Device End) | 8-Pin Mini-DIN (male, right-angle connector with lock mechanism) |
|---|
| Cable Length | 2 meters |
|---|
| Primary Compatibility | MicroLogix 1000 Controller to Hand-Held Programmer (HHP) Connections |
|---|
| Data Protocol | RS-232 serial communication |
|---|
| Minimum Operating Temperature | 0 °C |
|---|
| Maximum Operating Temperature | 60 °C |
|---|
| Minimum Storage Temperature | -40 °C |
|---|
| Maximum Storage Temperature | 85 °C |
|---|
| Operating Humidity Range | 5% to 95% (non-condensing) |
|---|
TECHNICAL INFORMATION
Features
- Provides direct point-to-point RS-232 serial link between controller and programmer.
- Features dual 8-pin Mini-DIN male connectors with right-angle molded boots.
- Integrated locking mechanisms prevent accidental disconnects during programming tasks.
- Factory molded 2-meter physical cable length ensures reach in control enclosures.
TECHNICAL INFORMATION
Applications
- Field programming of Allen-Bradley MicroLogix 1000 programmable logic controllers.
- Direct parameter adjustment using dedicated hand-held programmer units.
TECHNICAL INFORMATION
Connections / Interfaces
- Connector A features an 8-pin Mini-DIN male connector with an integrated mechanical lock.
- Connector B provides an identical 8-pin Mini-DIN male connector with a locking latch.
- Both ends utilize right-angle orientations to reduce clearance depth in enclosures.
- Pins transmit RS-232 serial communication signals between connected hardware.
TECHNICAL INFORMATION
Installation Guidelines
- Align the 8-pin Mini-DIN connector keyway with the controller communication socket.
- Press firmly until the mechanical locking mechanism engages completely.
- Avoid bending the cable beyond its natural bend radius near connector boots.
- Disengage the locking clip before removing the cable from any port.
TECHNICAL INFORMATION
Compatibility
- Designed for connection to Allen-Bradley MicroLogix 1000 controller communication ports.
- Connects directly to compatible Allen-Bradley hand-held programmers.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSDesigned for connection to Allen-Bradley MicroLogix 1000 controller communication ports. Connects directly to compatible Allen-Bradley hand-held programmers.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the 1761-CBL-HM02 cable?
The cable connects an Allen-Bradley MicroLogix 1000 controller to a hand-held programmer. It carries RS-232 serial communication.
What connector types are installed on the 1761-CBL-HM02?
Both ends feature right-angle 8-pin Mini-DIN male connectors with integrated locking mechanisms.
What is the length of the 1761-CBL-HM02 cable?
The cable measures 2 meters in total length.
