PRODUCT INFORMATION
Product Overview
The Allen-Bradley 1761-HHP-B30 is a dedicated Hand Held Programmer for MicroLogix 1000 controllers. It features a 2-line by 16-character liquid crystal display screen for programming and diagnostic tasks. Data entry uses a 30-key rubber and carbon keypad with color-coded key designations.
This device operates on a nominal line voltage of 24 VDC supplied from the controller. Communications link through an RS-232 port utilizing the DF1 full-duplex protocol. Users can create, edit, and modify ladder logic programs directly on plant floors. It also provides multi-point monitoring and program tracing capabilities in industrial environments.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Communication Type | RS-232 port supporting DF1 full-duplex protocol |
|---|
| Compatibility | MicroLogix 1000 controllers |
|---|
| Display Type | 2-line by 16-character LCD |
|---|
| Humidity Tolerance | 80% non-condensing |
|---|
| Input Interface | 30-key rubber/carbon keypad with color-coded keys |
|---|
| Installation Altitude | 1000 MSL |
|---|
| Line Voltage | 24 VDC |
|---|
| Monitoring Features | Trace and Multi-point monitoring |
|---|
| Operating Temperature | 0 to 40 °C |
|---|
| Product Line | MicroLogix 1000 |
|---|
| Programming Capabilities | Create, edit, and modify ladder logic programs |
|---|
| UPC | 66246848972 |
|---|
| Weight | 2.00 lbs (0.91 kg) |
|---|
TECHNICAL INFORMATION
Features
- Equipped with a 2-line by 16-character LCD screen for text and instruction display.
- Features a 30-key rubber and carbon keypad with color-coded operational buttons.
- Supports DF1 full-duplex protocol via an onboard RS-232 serial interface.
- Enables real-time trace monitoring and multi-point bit and data monitoring.
- Permits direct creation, editing, and modification of ladder logic programs.
TECHNICAL INFORMATION
Applications
- On-site programming and troubleshooting of Allen-Bradley MicroLogix 1000 programmable logic controllers.
- Field maintenance diagnostics without requiring a dedicated personal computer terminal.
- Real-time parameter modification and instruction monitoring in machine control panels.
TECHNICAL INFORMATION
Connections / Interfaces
- Contains an RS-232 serial communication interface for direct connection to MicroLogix 1000 processors.
- Draws operating power of 24 VDC directly through the dedicated peripheral cable connection.
TECHNICAL INFORMATION
Installation Guidelines
- Connect the programmer communication cable directly to the controller peripheral communication port.
- Verify that ambient operating temperatures stay between 0 and 40 °C.
- Ensure operating humidity does not exceed 80% non-condensing during operation.
- Maintain installation altitude below 1000 meters above mean sea level.
TECHNICAL INFORMATION
Configuration Guidelines
- Establish DF1 full-duplex communication settings matching the target MicroLogix 1000 controller.
- Use the color-coded keypad to navigate ladder rungs and instruction elements.
- Configure multi-point monitoring addresses to observe specific register values simultaneously.
TECHNICAL INFORMATION
Compatibility
- Specifically designed for use with Allen-Bradley MicroLogix 1000 controller family units.
TECHNICAL RESOURCES
Documentation
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSSpecifically designed for use with Allen-Bradley MicroLogix 1000 controller family units.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the Allen-Bradley 1761-HHP-B30?
It is a hand-held programming terminal used to create, edit, and monitor MicroLogix 1000 ladder logic.
Which communication protocol does the 1761-HHP-B30 utilize?
The device communicates over an RS-232 interface using the DF1 full-duplex protocol.
What operating power does the 1761-HHP-B30 require?
It operates on a line voltage of 24 VDC supplied through the controller connection.
What is the market reference price for the 1761-HHP-B30?
Observed market pricing ranges from 579.00 USD to 1069.00 USD depending on condition. These figures represent indicative market reference pricing only and are not a final quotation.
