PRODUCT INFORMATION
Product Overview
The Allen-Bradley 1769-BA is a battery unit designed for the CompactLogix system platform. This module functions with both Series A and Series B configurations. The unit features an open enclosure construction to promote airflow and heat dissipation. It provides dedicated energy storage for compatible Rockwell Automation control setups.
This battery module operates with a continuous electrical isolation rating of 30 volts. Backplane current draw is rated at 1.4 amperes at 24 volts direct current. The unit exhibits an overall power consumption rating of 33.6 watts. Power dissipation under normal operation is specified at 7.5 watts.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Category | PLCs |
|---|
| UPC | 612598312108 |
|---|
| Weight | 0.13 lbs (0.06 kg) |
|---|
| Module Type | Battery |
|---|
| Isolation Voltage | 30 Volts Continuous |
|---|
| Enclosure | Open |
|---|
| Backplane Current | 1.4 Amps at 24 Volts |
|---|
| Power Consumption | 33.6 Watts |
|---|
| Power Dissipation | 7.5 Watts |
|---|
TECHNICAL INFORMATION
Features
- Operates with a continuous electrical isolation rating of 30 volts.
- Compatible with both Series A and Series B CompactLogix configurations.
- Designed with an open enclosure structure to facilitate airflow.
- Draws a backplane current of 1.4 amps at 24 volts.
- Rated for 33.6 watts power consumption and 7.5 watts dissipation.
TECHNICAL INFORMATION
Applications
- Energy storage for compatible Allen-Bradley CompactLogix automation systems.
- Industrial automation cabinets using Series A or Series B configurations.
TECHNICAL INFORMATION
Installation Guidelines
- Install the unit within an open or enclosed industrial cabinet.
- Maintain operational electrical isolation within the continuous 30-volt limit.
- Ensure adequate ventilation around the open enclosure to dissipate heat.
TECHNICAL INFORMATION
Configuration Guidelines
- Verify system compatibility with Series A or Series B hardware platforms.
- Factor the 1.4 amp current draw at 24 volts into power budgets.
TECHNICAL INFORMATION
Compatibility
- Allen-Bradley CompactLogix Series A systems.
- Allen-Bradley CompactLogix Series B systems.
COMPATIBILITY
Compatibility & Replacement
COMPATIBLE MODELSAllen-Bradley CompactLogix Series A systems. Allen-Bradley CompactLogix Series B systems.
Verify compatibility against the exact Part Number, revision and manufacturer documentation before ordering.
PART VERIFICATION
Before You Order
Industrial automation parts can share similar model names, suffixes and revisions. Confirm the complete manufacturer Part Number before purchase.
01Check Part NumberMatch the complete ordering code on the existing unit.
02Confirm RevisionCheck suffix, hardware or firmware when applicable.
03Send a Label PhotoWe can review a clear label photo when identification is uncertain.
ORDERING PROCESS
From RFQ to Dispatch
1Submit Part Number2Verify Product Identity3Confirm Stock & Condition4Issue Quotation5Dispatch & Tracking
PRODUCT FAQ
Frequently Asked Questions
What is the primary function of the Allen-Bradley 1769-BA?
The 1769-BA functions as a dedicated battery unit for CompactLogix systems.
Which system series are compatible with the 1769-BA?
The unit is compatible with both Series A and Series B CompactLogix configurations.
What are the electrical power ratings of the 1769-BA?
It requires 1.4 amps at 24 volts backplane current and consumes 33.6 watts.
