Product Overview
The General Electric IC670CHS003 is an I/O terminal block belonging to the Field Control series. This unit provides field termination wiring interfaces for compatible Field Control I/O modules. It features a wire-to-board connector assembly configured with 20 connector pins per module. The terminal block supports an electrical current rating of up to 10.0 A per terminal.
Physical installation options include standard 35 mm DIN rail mounting or direct panel mounting. The unit provides an ingress protection rating of IP20 for indoor industrial environments. The operating temperature range spans from 0°C to 55°C under non-condensing relative humidity. Permissible storage temperatures range between -40°C and 85°C at altitudes up to 1000 meters.
TECHNICAL DATA
Technical Specifications
| Parameter | Specification |
|---|
| Weight | 0.38 lbs (0.17 kg) |
|---|
| Connector Type | Wire-to-Board |
|---|
| Number of Connector Pins | 20 pins per module |
|---|
| Current per Terminal | 10.0 A |
|---|
| Mounting Type | 35mm DIN rail or panel mounting |
|---|
| IP Rating | IP20 |
|---|
| Min. Operating Temperature | 0°C |
|---|
| Max. Operating Temperature | 55°C |
|---|
| Min. Storage Temperature | -40°C |
|---|
| Max. Storage Temperature | 85°C |
|---|
| Min. Relative Humidity | 5% (Non-Condensing) |
|---|
| Max. Relative Humidity | 95% (Non-Condensing) |
|---|
| Installation Altitude | 1000 m |
|---|
TECHNICAL INFORMATION
Features
- Features a 20-pin wire-to-board connector design for Field Control modules.
- Supports a maximum current capacity of 10.0 A per terminal.
- Mounts onto standard 35 mm DIN rail or directly to a flat panel.
- Rated IP20 for installation in enclosed industrial control cabinets.
- Accommodates non-condensing relative humidity levels between 5% and 95%.
TECHNICAL INFORMATION
Applications
- Field wiring termination for General Electric Field Control distributed I/O systems.
- Indoor industrial control panels requiring IP20 protected wire-to-board connections.
TECHNICAL INFORMATION
Connections / Interfaces
- Equipped with 20 connector pins for wire-to-board module connections.
- Rated to carry up to 10.0 A of current on each terminal connection.
TECHNICAL INFORMATION
Installation Guidelines
- Mount the terminal block onto a standard 35 mm DIN rail or secure it to a panel.
- Ensure operational altitude does not exceed 1000 meters above sea level.
- Maintain ambient operating temperatures within 0°C to 55°C inside the enclosure.
- Verify that relative humidity remains non-condensing between 5% and 95%.
